CXA1203M/N Datasheet

  • CXA1203M/N

  • 8mm VCR PAL JOG

  • 28頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

CXA1203M/N
8mm VCR PAL JOG
Description
The CXA1203M/N compensates the color alignment
in variable speed mode for PAL-system 8mm VCRs.
This IC is also available for the SECAM system with
the built-in SECAM detector and BELL and C-BELL
filters.
Features
鈥?/div>
Color alignment compensation which does not
require 1H delay line
鈥?/div>
No AFC (f
H
) adjustment necessary
鈥?/div>
Built-in SECAM detector
鈥?/div>
Built-in BELL and C-BELL filters
鈥?/div>
Available for the PAL-M system
Functions
V-Invert circuit, TH/DL APC, 2fsc PLL, SQ DET,
EX burst circuit, AFC (f
H
), Timing generator,
SECAM detector, BELL filter, C-BELL filter
Structure
Silicon monolithic IC
Absolute Maximum Ratings
(Ta = 25擄C)
7.0
鈥?/div>
Supply voltage
V
CC
鈥?/div>
Operating temperature Topr 鈥?0 to +75
鈥?/div>
Storage temperature
Tstg
鈥?5 to +150
567
536
鈥?/div>
Allowable power dissipation
P
D
CXA1203M
CXA1203N
CXA1203M
24 pin SOP (Plastic)
CXA1203N
24 pin SSOP (Plastic)
V
擄C
擄C
mW
mW
Recommended Operating Conditions
Supply voltage
4.5 to 5.5
(5.0V typ.)
V
Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by
any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the
operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.
鈥?鈥?/div>
E01Z33-PS
