Network Processing and VoIP
Home Network Processors
Network Processor with Integrated
Ethernet Switch and USB2.0 Support
CX86201/2
Single-Chip Solution with Integrated Five-Port
Ethernet Switch and USB2.0 Host Support
Conexant鈥檚 broadband communications portfolio includes a comprehensive
suite of semiconductor solutions that enable the digital home and information
network. The Conexant CX8620x Network Processor supports complete
networking system solutions for a wide variety of mainstream applications in
the residential and SOHO environments. Based on a 180 MHz ARM926, this
network processor is a single-chip solution with an integrated switch that
supports five 10/100 Mbps Ethernet ports with auto MDIX capabilities.
In a broadband gateway application, the CX8620x network processor can
provide Internet access sharing capability for multiple PCs, while supporting
Ethernet, 802.11 through a PCI interface and any USB2.0 device including
hard disk drives and printers. For WAN access, the unit supports Ethernet
connectivity interoperable with any broadband modem. It is the ideal platform
for a configurable broadband gateway design that needs to accommodate
many diverse WAN/LAN topologies.
The device complies with IEEE 802.3 specification and includes five
embedded DSP-based 10Base-T/100Base-TX transceivers. An auto
negotiation function determines the selection of either the 10Base-T or
100Base-Tx mode. Typical applications would be a wireless home gateway
including an Ethernet WAN port to connect to a broadband modem, four
Ethernet LAN ports, an 802.11 a/b/g access point connecting any Wi-Fi
compatible device and a home storage device connected through the
USB2.0 host.
Distinguishing Features
鈥?Single-Chip, high-performance
processor with an integrated five-port
Ethernet switch supporting auto MDIX
鈥?PCI host for a wide range of
applications including the 802.11 a/b/g
wireless protocols and video
compression devices
鈥?Advanced Serial and VoIP capabilities
(only CX86202)
PC
PC
鈥?An MMU for Linux and WinCE support
鈥?Supports high speed secure VPN
implementations
USB2.0
transceiver
USB Host
Hard Disk
Drive
CX8620x
Internet
Broadband
Modem
Ethernet
802.11 a/b/g
Device
G.7xx DSP
PCI/PCMCIA
SLIC/
SLAC
Serial
Phone
PC
PC
Part Number
CX86201/2
Secure 802.11a/b/g Gateway with Storage and VoIP Support
Description
Network Processor with Integrated
Ethernet Switch and USB2.0
CONEXANT
