CX65002
700 鈥?1000 MHz Linear Power Amplifier Driver
Conexant鈥檚 CX65002 Microwave Monolithic Integrated Circuit (MMIC) power
amplifier driver offers a desirable combination of features that provide superb
performance and ease of use in a low-cost Surface-Mounted Technology (SMT)
package. The Gallium Arsenide (GaAs) Heterojunction Bipolar Transistor (HBT)
power amplifer driver was developed and optimized for extreme linear performance
in a variety of applications. It is ideal as a driver or output stage for transceivers
and repeaters in AMPS/CDMA/TDMA/GSM paging base stations, mobile radios,
telematics, and many other applications.
Figure 1 shows a functional block diagram for the CX65002. The device package
and pinout are shown in Figure 2.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
5 V single supply operation
Excellent linearity
Wide dynamic range
Broad frequency coverage
Internal bias circuits
Surface mounted Small Outline Integrated Circuit
(SOIC) 8-pin package with downset paddle
Applications
鈥?/div>
AMPS/CDMA/TDMA/GSM
鈥?/div>
Wireless Local Loop (WLL) and Industrial,
Scientific, Medical (ISM) bands
鈥?/div>
Repeaters
鈥?/div>
Paging
鈥?/div>
Mobile radios
鈥?/div>
Telematics
鈥?/div>
VHF/UHF TV broadcast
VCC1
VCC2
8
5
Driver Bias
4
Y
NC
1
8
VCC1
VB
RFIN
2
Input Bias
DA
6, 7
VB
2
7
RFOUT
3
RFOUT
RFIN
3
6
RFOUT
Y
C1216
4
5
VCC2
C1215
Figure 1. CX65002 Functional Block Diagram
Figure 2. CX65002 Pinout 鈥?8-Pin SOIC Package
Top View
Data Sheet
Conexant - Preliminary
Proprietary Information and Specifications Are Subject to Change
Doc. No. 101467B
October 26, 2001
