Cable Modems
Electrical Specifications @ 25擄C 鈥?Operating Temperature -40擄C to +85擄C
Part
Number
Frequency
(MHz)
Z
(鈩?
Isolation
(dB TYP/MIN)
Return Loss
INPUT
OUTPUT
(dB TYP/MAX) (dB TYP/MAX)
Mainline Loss
>3dB
Flatness
(dB TYP/MAX)
(dB MAX)
Phase Unbalance
(deg MAX)
1擄
Amplitude Unbalance
(dB MAX)
0.30
CX4005
5 - 250
75
>24/22
>27/25
>24/20
<0.45/0.75
鹵0.25
NOTE: CX4005
has an internal terminating resistor. For parts without internal terminating resistor use part CX4005A.
Mechanical
CX4005
.200
5,08
.100
2,54
.130
3,30
.310
7,87
DATE CODE
CTRY ORIGIN
.310
MAX
7,87
.090
2,29
INPUT
1
6
GND
.255
MAX
6,48
NC
2
5
NC
CX4005
.050
1,27
PIN 1
IDENTIFICATION
PORT 1
3
4
PORT 2
SUGGESTED PAD LAYOUT
PIN 1
IDENTIFICATION
Power Rating: 1 Watt, MAX
.210
MAX
5,33
.100
2,54
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are 鹵 .005
0,13
.200
5,08
.040
1,02
6 PL
Weight
. . . . . . . . . . .0.35 grams
Tape & Reel
. . . . . . . . .850/reel
Tube
. . . . . . . . . . . . . . .65/tube
BOTTOM VIEW
US 858 674 8100
鈥?/div>
UK 44 1483 401 700
鈥?/div>
France 33 3 84 35 04 04
鈥?/div>
Singapore 65 287 8998
鈥?/div>
Taiwan 886 2 2698 0228
鈥?/div>
Hong Kong 852 2788 6588
鈥?/div>
http://www.pulseeng.com
PRELIMINARY C226.P (9/02)
