CX28394/28395/28398

Quad/x16/Octal鈥擳1/E1/J1 Framers

The CX28394/28395/28398 is a family of multiple framers for T1/E1/J1 and Integrated

Service Digital Network (ISDN) primary rate interfaces operating at 1.544 Mbps or 2.048

Mbps. All framers are totally independent, and each combines a sophisticated framing

synchronizer and transmit/receive slip buffers. Operations are controlled through a

series of memory-mapped registers accessible via a parallel microprocessor port.

Extensive register support is provided for alarm and error monitoring, signaling

supervision (including ISDN D-channel/SS7 process), per-channel trunk conditioning,

and Facility Data Link (FDL) maintenance. A flexible serial Time Division Multiplexed

(TDM) system interface that supports bus rates from 1.536 to 8.192 MHz is featured.

Extensive test and diagnostic functions include a full set of loopbacks, Pseudo Random

Bit Sequence (PRBS) test pattern generation, Bit Error Rate (BER) meter, and forced

error insertion.

Distinguishing Features

鈥?/div>

Up to 16 T1/E1/J1 Framers in one

package

Extensive support of various

protocols

T1: SF, ESF, SLC

廬

96, T1DM,

TTC JT(J1)

E1: PCM-30, G.704, G.706, G.732,

ISDN primary rate (ETS300 011,

INS 500)

Extracts and inserts signaling bits

Dual HDLC controllers per framer for

data link and LAPD/SS7 signaling

Two-frame transmit and receive PCM

slip buffers

Separate or multiplexed system bus

interfaces

Parallel 8-bit microprocessor port

supports Intel or Motorola buses

BERT generation and counting

B8ZS/HDB3/Bit 7 zero suppression

(CX28394 and CX28398 only)

Operates from a single +3.3 Vdc

鹵

5% power supply

Low-power CMOS technology

鈥?/div>

Functional Block Diagram

鈥?/div>

Receive

Dual Rail or

NRZ

Slip

Buffer

Receive

System

Bus

鈥?/div>

ZCS*

Decode

T1/E1

Receive

Framer

Receive

Dual Rail or

NRZ

ZCS*

Encode

Overhead

Insertion

Slip

Buffer

T1/E1

Transmit

Framer

Transmit

System

Bus

Applications

鈥?/div>

Multiline T1/E1 Channel Service

Unit/Data Service Unit (CSU/DSU)

Digital Access Cross-Connect

System (DACS)

T1/E1 Multiplexer (MUX)

PBXs and PCM channel bank

ISDN Primary Rate Access (PRA)

Frame Relay Switches and Access

Devices (FRADS)

SONET/SDH add/drop multiplexers

T3/E3 channelized access

concentrators

Data Link Controllers

DL1+DL2

鈥?/div>

Framer #1

External Data Link

DL3*

Framer #N

Control/Status

Registers

Framer #N

8394-8-5_019

JTAG

Test Port

* CX28394 and CX28398 only.

Motorola/Intel

Processor Bus

CX28394 - 4 Frames

CX28398 - 8 Frames

CX28395 - 16 Frames

Data Sheet

100054E

June 2000
