Solutions on a chip for enjoying the digital life style
NTSC/PAL/SECAM Adaptive 2D
Comb
Filter Video Decoder
CVD1
Product Brief
Zoran Corporation
3112 Scott Boulevard
Santa Clara, CA 95054-3317
T e l 408.919.4 1 1 1
Fax 408.919.4122
www.zoran.com
廬
Description
Zoran鈥檚 CVD1 Video Decoder is a silicon efficient, cost effective,
high video quality Intellectual Property Core for IC designs requiring
video input. The CVD1 decodes NTSC/PAL/SECAM composite
video or S-video and converts it into YUV 4:2:2, 16-bit digital video.
Employing adaptive 2D comb filter technology, the CVD1 is able
to provide high quality Y/C separation while maintaining excellent
frequency response.
The result is sharp, high detail video that eliminates unwanted dot
crawl and false color effects. A fully digital design, the CVD1
requires the addition of only an A/D (two for S-Video support),
a DC restore circuit and line buffers for implementation.
CVD1 is based on Zoran鈥檚 extensive experience delivering high
quality, high volume video ICs to major OEMs worldwide.
Proven in silicon, the CVD1 Video Decoder greatly reduces the
risk and time involved when integrating the video decoding
function into an IC.
Deliverables
鈥?RTL (Verilog) source code
鈥?Bit accurate C++ model
鈥?Synopsis synthesis scripts
鈥?Test input files
鈥?Documentation
鈥?FPGA evaluation board available
Features
鈥?Decodes NTSC, PAL or SECAM composite video or S-Video into
the YUV 4:2:2 format
鈥?Component video inputs supported
鈥?Decodes all variations of the NTSC standard
鈥?Decodes all variations of PAL standard
鈥?(I, B, G, H, D, N, M, combination N)
鈥?Excellent quality Y/C separation
鈥?minimizes cross luma and cross color effects
鈥?Superior frequency response preserves fine detail
鈥?Accepts up to 11-bit inputs from A/D converter
鈥?Digital automatic gain control (AGC) supported
鈥?Adaptive 2D Comb Filter provides high quality video:
鈥?3-line 2D Comb Filter for NTSC & PAL
鈥?5-line 2D Comb Filter for PAL (optional)
鈥?Auto-detects video standard (NTSC, PAL or SECAM)
鈥?Auto-detects and locks to VCR trick modes
鈥?Decodes weak and noisy off-air signals
鈥?Auto-detects and decodes Macrovision copy protection
鈥?VBI decoding supported
鈥?Silicon efficient design of approximately 130k gates
鈥?Requires only a single clock input ranging from 20 to 30 MHz
鈥?Process technology independent, fully synchronous design
Applications
鈥?LCD controllers
鈥?Digital TV decoders
鈥?Game processors
鈥?PC video capture devices
鈥?Set top box decoders
鈥?Any IC requiring video input
