CVA24150T Datasheet

  • CVA24150T

  • 180V CRT Driver

  • 61.32KB

  • 5頁

  • CALOGIC   CALOGIC

掃碼查看芯片數據手冊

上傳產品規(guī)格書

PDF預覽

180V CRT Driver
CORPORATION
CVA24150T
FEATURES
DESCRIPTION
The CVA24150T is a single channel, very high voltage
amplifier, designed to drive a CRT. It is capable of delivering
65MHz at 100V
P-P
. It features no cross-over distortion for
excellent linearity. Emitter peaking option is available to
adjust the high frequency response. CVA24150T features
high gain to match existing pre-amplifier drive capability.
鈥?/div>
Fall Time (C
LOAD
= 10pf) . . . . . . . . . . . . . . . . . . . . . . 10ns
鈥?/div>
RiseTime (C
LOAD
= 10pf) . . . . . . . . . . . . . . . . . . . . . . . 7ns
鈥?/div>
Fall Time (C
LOAD
= 20pf) .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 13ns
10ns
鈥?/div>
RiseTime (C
LOAD
= 20pf)
鈥?/div>
Fall Time (C
LOAD
= 30pf) . . . . . . . . . . . . . . . . . . . . . . 15ns
. . 13ns
鈥?/div>
RiseTime (C
LOAD
. = .30pf) .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . 100Vp-p
Swing Voltage . . . . . .
鈥?/div>
鈥?/div>
Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180V
鈥?/div>
Low Power
鈥?/div>
Smaller Package
鈥?/div>
High Definition Television
鈥?/div>
Projection Television
鈥?/div>
Arcades
鈥?/div>
TV Monitors
CONNECTION DIAGRAM
BENEFITS
ORDERING INFORMATION
Part
CVA24150T
Package
T11A
Temperature
-20
o
C to +100
o
C
APPLICATIONS
SIMPLIFIED SCHEMATIC DIAGRAM
V
CC
11
10
9
8
7
6
N/C
5
GND
4
3
2
1
GND
EMITTER
PEAKING
N/C
V
OUT
11
V
CC
V
OUT
N/C
V
OUT
8,9
V
BIAS
V
IN
1
V
IN
V
BIAS
2
TAB = GND
TOP VIEW
T11A PACKAGE
1P-06
3
EMITTER
PEAKING
4,5
1P-07
CALOGIC CORPORATION,
237 Whitney Place, Fremont, California 94539, Telephone: 510-656-2900, FAX: 510-651-3025
