CT2553 / 2554 / 2555 / 2556

Advanced Integrated MUX (AIM) Hybrid

FOR MIL-STD-1553

Features

I

A E

RO

I

Second Source Compatible to the BUS-61553

Complete Integrated MUX Including:

鈥?/div>

Low Power Dual Transceiver

鈥?/div>

BC/RTU/MT Protocol

鈥?/div>

8K x 16 Shared Ram

鈥?/div>

Interrupt Logic

Compatible with MIL-STD- 1750 and other Standard CPUs

DIP or Flatpack Hybrid

Minimizes CPU Overhead

Provides Memory Mapped 1553 Interface

On-Line & Off-Line Self-Test

PCs Development Tools Available

SEAFAC Tested

MIL-PRF-38534 compliant circuits available

DESC SMD #5962鈥?8692 Pending

Packaging 鈥?Hermetic Metal

鈥?/div>

78 Pin, 2.1" x 1.87" x .25" Plug-In type package

鈥?/div>

82 Lead, 2.2" x 1.61" x .18" Flat package

CIRCUIT TECHNOLOGY

www.aeroflex.com

F

LE

X

LA

C

ISO

9001

E

RT

I

F

I

E

D

B

S

I

NC

.

General Description

Aeroflex鈥檚 CT2553 Advanced Integrated Mux (AIM) Hybrid is a complete MIL-STD-1553 Bus

Controller (BC), Remote Terminal Unit (RTU), and Bus Monitor (MT) device. Packaged in a single

78 pin DIP package, the CT2553 contains dual low-power transceivers, complete BC/RTU/MT

protocol logic, a MIL-STD-1553-to-host interface unit and an 8K x 16 RAM.

Using an industry standard dual transceiver and standard status and control signals, the CT2553

simplifies system integration at both the MIL-STD-1553 and host processor interface levels.

All 1553 operations are controlled through the CPU access to the shared 8K x 16 RAM. To ensure

maximum design flexibility, memory control lines are provided for attaching external RAM to the

CT2553 Address and Data Buses and for disabling internal memory; the total combined memory

space can be expanded to 64K x16. All 1553 transfers are entirely memory-mapped; thus the CPU

interface requires minimal hardware and/or software support.

The CT2553 operates over the full military -55擄C to +125擄C temperature range. Available screened

to MIL-STD883, the CT2553 is ideal for demanding military and industrial microprocessor to 1553

interface applications.

See "Ordering Information" (last sheet) for CT2554, CT2555 & CT2556.

eroflex Circuit T

echnology

鈥?Data Bus Modules For The Future 漏 SCDCT2553 REV B 8/6/99
