CD1005-B0130L Datasheet

  • CD1005-B0130L

  • Small Signal Diode; Forward Current, If(AV):100mA; Repetitiv...

  • 0頁

  • Bourns   Bourns

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

IA
NT
Features
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
Applications
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
Lead free as standard
RoHS compliant*
Leadless
Low stored charge
Cellular phones
PDAs
Desktop PCs and notebooks
Digital cameras
MP3 players
*R
oH
S
CO
M
PL
CD0603/1005 Schottky Barrier Chip Diode Series
General Information
The markets of portable communications, computing and video equipment are challenging the semiconductor industry to develop increasingly
smaller electronic components.
Bourns offers small-signal high-speed Schottky Barrier Diodes for switching and rectification applications, in compact chip package 0603 and
1005 size format, which offer PCB real estate savings and are considerably smaller than most competitive parts. The Schottky Barrier Diodes
offer a forward current of 30 mA, 100 mA or 200 mA, a reverse voltage of 30 V and 40 V and also have a low forward voltage option. The
diodes are lead free with Cu/Ni/Au plated terminations and are compatible with lead free manufacturing processes, conforming to many
industry and government regulations on lead free components.
Bourns
廬
Chip Diodes conform to JEDEC standards, easy to handle on standard pick and place equipment and their flat configuration makes
roll away much more difficult.
Electrical Characteristics (@ TA = 25 擄C Unless Otherwise Noted)
Parameter
Symbol
CDxxxx-
B00340
CDxxxx-
B0130L
CDxxxx-
B0140L
CDxxxx-
B0140R
CDxxxx-
B0230
CDxxxx-
B0240
Unit
Forward Voltage (Max.)
Capacitance Between
Terminals (Max.)
(f = 1 MHz)
Reverse Current (Max.)
VF
CT
IR
0.37
(If = 1 mA)
1.5
(Vr = 1 V)
1
(Vr = 40 V)
0.44
(If = 0.1 A)
9
(Vr = 10 V)
30
(Vr = 30 V)
0.55
(If = 0.1 A)
9
(Vr = 10 V)
30
(Vr = 10 V)
0.45
(If = 0.01 A)
9
(Vr = 10 V)
1
(Vr = 10 V)
0.50
(If = 0.2 A)
12
(Vr = 10 V)
30
(Vr = 30 V)
0.55
(If = 0.2 A)
12
(Vr = 10 V)
10
(Vr = 30 V)
V
pF
碌A(chǔ)
How To Order
CD 0603 - B 01 30 L
Common Code
Chip Diode
Package
鈥?0603
鈥?1005
Model
B = Schottky Barrier Series
Average Forward Current (Io) Code
003 = 30 mA
01 = 100 mA
02 = 200 mA
(Code x 1000 mA = Average Forward Current)
Reverse Voltage (VR) Code
30 = 30 V
40 = 40 V
Forward Voltage Suffix
L = Low Forward Voltage Vf (CDxxxx-B0130L)
R = Low Reverse Current VR (CDxxxx-B0140R)
*RoHS Directive 2002/95/EC Jan 27 2003 including Annex
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.

CD1005-B0130L 產品屬性

  • 1

  • 分離式半導體產品

  • 單二極管/整流器

  • -

  • 肖特基

  • 30V

  • 100mA

  • 440mV @ 100mA

  • 小信號 =

  • -

  • 30µA @ 30V

  • -

  • *

  • *

  • *

  • *

  • CD1005-B0130LDKR
