CAT24C01C
1K-Bit Serial EEPROM
FEATURES
s
400 KHZ I
2
C Bus Compatible*
s
1.8 to 6.0Volt Operation
s
Low Power CMOS Technology
s
Page Write Buffer
s
Self-Timed Write Cycle with Auto-Clear
s
1,000,000 Program/Erase Cycles
s
100 Year Data Retention
DESCRIPTION
The CAT24C01C is a 1K-bit Serial CMOS EEPROM
internally organized as 128 words of 8 bits each. Catalyst鈥檚
advanced CMOS technology substantially reduces de-
vice power requirements. The the CAT24C01C features
a 16-byte page write buffer. The device operates via the
I
2
C bus serial interface and has a ISO 7816 compatible
pinout for smartcard micromodule applications.
DIE PAD CONFIGURATION
DC
DC
BLOCK DIAGRAM
EXTERNAL LOAD
DOUT
ACK
SENSE AMPS
SHIFT REGISTERS
GND
VDD
VCC
VSS
WORD ADDRESS
BUFFERS
COLUMN
DECODERS
SDA
NC
SDA
START/STOP
LOGIC
NC
SCL
CONTROL
LOGIC
XDEC
E
2
PROM
DATA IN STORAGE
PIN FUNCTIONS
Pin Name
NC
SDA
SCL
V
CC
V
SS
DC
Function
No Connect
Serial Data/Address
Serial Clock
+1.8V to +6.0V Power Supply
Ground
Don't Connect
SCL
STATE COUNTERS
SLAVE
ADDRESS
COMPARATORS
HIGH VOLTAGE/
TIMING CONTROL
* Catalyst Semiconductor is licensed by Philips Corporation to carry the I
2
C Bus Protocol.
漏 2003 by Catalyst Semiconductor, Inc.
Characteristics subject to change without notice
1
Doc. No. 1041, Rev. A
