Solutions on a chip for enjoying the digital life style
CamMini
T M
5
Reference Design Kit
CamMini 5
Product Brief
Zoran Corporation
3112 Scott Boulevard
Santa Clara, CA 95054-3317
T e l 408.919.4 1 1 1
Fax 408.919.4122
www.zoran.com
廬
Description
The CamMini
5
(ZR83643003) is a copy ready reference design for
1.3 megapixel point-and-shoot digital still or dual-mode cameras
(DSCs). The CamMini
5
offers customers an optimized low cost,
ultracompact camera solution that is feature rich and delivers high
quality still photos. The design is based on a suite of key Zoran
components including the COACH processor and PixelCam
C1300
1/3.4"
1.3Mpixel CMOS image sensor, which combined accelerates and
simplifies the design and manufacturing process. Incorporated within
the CamMini
5
are exciting features such as MP3 playback, AVI
video capture and Zoran鈥檚 exclusive, 鈥淶-Time鈥?feature, which
enables megapixel images to be taken at essentially zero click-click
time. This configuration represents the ideal balance between cost
and function. This 2nd generation chip combination allows for
optimal image tuning and the fastest time to market The design can
be customized for products ranging from entry level to full-featured.
Standard Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
High quality true 1.3 Megapixel still photography
Burst-mode multi-megapixel still shot series
Effectively zero
"click-to-click"
time megapixel still shots
Lens Shading image enhancement
Live CIF resolution video camera over USB
Auto-exposure and multi-mode white balance
5 developer-configurable camera control buttons
Audio annotation
On-chip USB line drivers
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Composite NTSC/PAL TV output
AVI capture; CIF@25fps w/audio
Panel or status LCD display
CompactFlash/SD/MMC port
"Accelerated
Playback"
MP3 playback
Operates on 2AA batteries
Up to 3x Smooth digital zoom
Deliverables
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Fully-functional CamMini
5
unit
Circuit board layout guidelines & Gerber files
Latest firmware release code & modification tools
Detailed BOM & schematics with optional configurations
PC Drivers; WHQL approved USB driver kits for image transfer
and video capture
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Reference user interface code sources
COACH Specs
PixelCam
C1300
1/3.4鈥?Sensor Specs
QuickLens Specs
06/02-LD
ZR83643003-PB-2.0
