CA3450
January 1999
File Number
1732.5
220MHz, Video Line Driver, High Speed
Operational Ampli鏗乪r
The CA3450 is a large signal video line driver and high
speed operational ampli鏗乪r capable of driving 50鈩?/div>
transmission lines and 鏗俛sh A/Ds. The uncompensated unity
gain crossing occurs at 230MHz without load. It can operate
at dual or single supplies of
鹵7.25V
or 14.5V, respectively.
The CA3450 can be compensated with a single capacitor
network. It has output drive capability of 75mA SINK or
SOURCE. The CA3450 is capable of driving Flash A/Ds in
video or high speed instrumentation (accurate) applications
with bandwidth up to 10MHz. Offset voltage nulling terminals
are also available.
Features
鈥?High Open Loop Gain at Video Frequencies
- A
OL
. . . . . . . . . . . . . . . . . . . . . . . . . . >40dB at f = 5MHz
鈥?Power Bandwidth of 10MHz . . . . . . . A
CL
= 5; V
O
=
鹵3.5V
鈥?Slew Rate at Full Load . . . . . . . . . . . . . 330V/碌s (A
V
鈮?/div>
10)
鈥?f
T
= 220MHz; C
C
= 0pF With a Load of 50鈩?||20pF|| 1M鈩?/div>
(Scope Input)
鈥?V
OUT
=
鹵4.1V
Into 75鈩?/div>
鈥?Offset Null Terminals
Applications
鈥?Video Line Driver
鈥?High Frequency Unity Gain Buffer
鈥?Pulse Ampli鏗乪r
鈥?High Speed Comparator
Pinout
CA3450
(PDIP)
TOP VIEW
OFFSET NULL 1
NC 2
- INPUT 3
V- 4
V- 5
V
O
6
V+ 7
V+ 8
16 OFFSET NULL
15 NC
14 + INPUT
13 V-
12 V-
11 COMP
10 NC
9 COMP
鈥?High Frequency Oscillator and Video Ampli鏗乪rs
鈥?Driver for A/Ds in Video Applications . . . . . . . .10MHz BW
Part Number Information
PART NUMBER
CA3450E
TEMP.
RANGE (
o
C)
-40 to 85
PACKAGE
16 Ld PDIP
PKG.
NO.
E16.3
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143
|
Copyright
漏
Intersil Corporation 1999
