CA1249 Integrated Half-Rate
Clock Driver and Phase Shifter
WJ鈥檚 10Gbps clock ampli鏗乪r
An RF evolution for OC-192
The CA1249 is another addition in WJ鈥檚 series of
hybrid-based products optimized for OC-192 networks.
The CA1249 is a full-function clock driver for generat-
ing transmit pulses in optical RZ systems operating
with clock rates between 10.7 and 12.5 GHz (up to
12.5 Gbps FEC data rates). The CA1249 ampli鏗乪s
clock signals while providing analog phase shift con-
trol. Excellent phase shift accuracy, low phase varia-
tion over temperature and stable output level perform-
ance work in conjunction with the integral power
鈥?10.7 to 12.5 Gbps Clock Rates
Tunable 200MHz about any Fo
鈥?360藲Analog Phase Shift Range
鈥?16 Vp-p Output Voltage
鈥?Fully Quali鏗乪d
detector to ensure precise control of transmitted pulses.
The CA1249鈥檚 efficiency enables high output voltage
levels with low power consumption. Custom perform-
ance and functionality are available
THE COMMUNICATIONS EDGE
鈩?/div>
WJ Communications, Inc
1-866-618-7704 鈥?408-577-6620 fax 鈥?sales@wj.com
