C9822EQ Datasheet

  • C9822EQ

  • SINGLE CLOCK DRIVER|SSOP|24PIN|PLASTIC

  • 19頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

APPROVED PRODUCT
C9822
Direct Rambus
餂?/div>
III Clock Generator
Product Features
鈥?/div>
High Speed Clock support - provides a 267 to
400MHz differential clock source for Direct
Rambus餂?memory systems for an 1.6 GbPS data
transfer rate
Synchronization Flexibility - provides signals to
synchronize the clock domains of the Rambus餂?/div>
Channel with an external system or processor
clock, provided by C9801, C9812, C9830, C9840,
C9850, C9851, and C9853.
Power Management Support permits channel
clocks to be enabled and disabled as required
Supports Independent Channel Clocking
24 pin 150 mil SSOP Package
Supports Intel Architecture platforms
Product Description
The C9822 is a Rambus餂?compliant DRCG clock
synchronizer. It contains a Phase Locked Loop that
provides complimentary Rambus餂?memory clocks.
Included in its functionality is the control logic to phase
and frequency synchronizing the device鈥檚 output clocks
with the system reference clock. Power management
logic is also provided for Mobile application and green
PC functionality. Also included are separate power pins
for each internal functional block so as to minimize
interaction of these sections with each other and thus
maximize the device performance.
