IMAGE SENSOR
InGaAs multichannel detector head
C8060/C8061/C8062-01
Designed for InGaAs linear image sensor
C8060/C8061/C8062-01 series are high sensitivity multichannel detector heads for use with InGaAs linear image sensors. C8060-01
is designed for the non-cooled InGaAs linear image sensors, while C8061-01 and C8062-01 for the thermoelectrically cooled InGaAs
linear image sensors for detection at even lower light levels.
C8060/C8061-01 and C8062-01 incorporate a low-noise driver/amplifier circuit that provide reliable operation from simple external
signals. C8061-01 and C8062-01 also include a highly stable temperature controller that cools the sensor to a preset temperature
level (C8061-01: Ts= -10 藲C, C8062-01: Ts= -20 藲C) as soon as the power is turned on. If the cooler fails and overheat occurs, the
built-in protection circuit automatically turns off the power to maintain safety. Despite its compact size, the housing configuration is
designed for good heat dissipation, and threaded mounting holes on the front panel allow connections to other devices such as
Features
Applications
l
Designed for InGaAs linear image sensor
C8061/C8062-01: TE-cooled type
C8060-01: non-cooled type
l
Built-in driver/amplifier and temperature circuit
l
Highly stable temperature controller (C8061/C8062-01)
Cooling temperature (Ta=10 to 30 藲C)
fixed at -10 鹵 0.1 藲C (C8061-01), -20 鹵 0.1 藲C (C8062-01)
l
Simple signal input operation
l
Compact configuration
l
Near infrared multichannel spectroscopy
l
Radiation thermometry
l
Non-destructive inspection
l
Optical fiber transmittance measurement
I
Selection Guide
The table below shows InGaAs image sensors applicable for the C8061/C8060/C8062-01.
Scince the C8061/C8060/C8062-01 do not include a
InGaAs image sensor, so select the desired sensor and order it
sparately.
Type No.
Type No.
G9201-256R
G9202-512R
G9203-256R
G9204-512R
G9201-256S
G9202-512S
G9203-256S
G9204-512S
G9211-256S
G9212-512S
G9213-256S
G9214-512S
G9205-256W
G9206-256W
G9207-256W
G9208-256W
Cooling
non-cooling
C8060-01
C8061-01
One-stage
TE-cooled
InGaAs linear image sensor
Number of
Number of
Pixel size
Active area
*1
pixels
active pixels
[碌m(H) 脳 碌m(V)] [mm (H) 脳 mm (V)]
256
256
50 脳 250
12.8 脳 0.25
512
512
25 脳 250
12.8 脳 0.25
256
256
50 脳 500
12.8 脳 0.50
512
512
25 脳 500
12.8 脳 0.50
256
256
50 脳 250
12.8 脳 0.25
512
512
25 脳 250
12.8 脳 0.25
256
256
50 脳 500
12.8 脳 0.50
512
512
25 脳 500
12.8 脳 0.50
256
>251
50 脳 250
12.8 脳 0.25
512
>502
25 脳 250
12.8 脳 0.25
256
>251
50 脳 500
12.8 脳 0.50
512
>502
25 脳 500
12.8 脳 0.50
256
>244
50 脳 250
12.8 脳 0.25
C8062-01
Two-stage
TE-cooled
*1: Number of active pixels: The total number of pixels whose dark current and sensitivity uniformity do not exceed the maximum values.
