C8051F206 Datasheet

  • C8051F206

  • 25 MIPS|8k Flash|1.25k RAM|12bit ADC|48-Pin MCU

  • 134頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

C8051F206
C8051F220/1/6
C8051F230/1/6
Mixed-Signal 8KB ISP FLASH MCU Family
ANALOG PERIPHERALS
-
SAR ADC
鈥?/div>
12-bit Resolution (鈥楩206)
鈥?/div>
8-Bit Resolution (鈥楩220/1/6)
鈥?/div>
鹵1/4
LSB INL (8-bit) and
鹵2
LSB INL (12-bit)
鈥?/div>
Up to 100ksps
鈥?/div>
Up to 32 Channel Input Multiplexer; Each Port
I/O Pin can be an ADC Input
Two Comparators
鈥?/div>
16 Programmable Hysteresis States
鈥?/div>
Configurable to Generate Interrupts or Reset
VDD Monitor
and
Brown-out Detector
On-Chip Debug Circuitry Facilitates Full Speed, Non-
intrusive In-system Debug (No
Emulator Required!)
Provides Breakpoints, Single-Stepping, Watchpoints,
Stack Monitor
Inspect/Modify Memory and Registers
Superior Performance to Emulation Systems Using
ICE-Chips, Target Pods, and Sockets
Complete, Low Cost Development Kit.
HIGH SPEED 8051
碌
C Core
-
-
-
-
-
-
Pipelined Instruction Architecture; Executes 70% of
Instructions in 1 or 2 System Clocks
Up to 25MIPS Throughput with 25MHz Clock
Expanded Interrupt Handler
256 Bytes Internal Data RAM
1024 Bytes XRAM (available on 鈥楩206/226/236)
8k Bytes FLASH; In-System Programmable in 512
byte Sectors
Four byte wide Port I/O; All are 5V tolerant
Hardware UART and SPI bus
3 General Purpose 16-Bit Counter/Timers
Dedicated Watch-Dog Timer
Bi-directional Reset
System Clock: Internal Programmable Oscillator,
External Crystal, External RC, or External Clock
MEMORY
-
-
-
-
-
-
-
DIGITAL PERIPHERALS
-
-
-
-
-
-
ON-CHIP JTAG DEBUG
SUPPLY VOLTAGE ................. 2.7V to 3.6V
-
Typical Operating Current: 10mA @ 25MHz
-
Multiple Power Saving Sleep and Shutdown Modes
(48-Pin TQFP and 32-Pin LQFP Version Available)
Temperature Range: 鈥?0擄C to +85擄C
擄
擄
ANALOG PERIPHERALS
AMUX
DIGITAL I/O
SPI Bus
UART
Timer 0
Digital MUX
PGA
SAR
+
-
+
-
Timer 1
VOLTAGE
COMPARATORS
Timer 2
HIGH-SPEED CONTROLLER CORE
8051 CPU
CLOCK
EMULATION
JTAG
(25MIPS)
CIRCUIT
CIRCUITRY
8K x 8
SANITY
1280 x 8
22 INTERRUPTS
ISP FLASH
SRAM
CONTROL
Page 1
CYGNAL Integrated Products, Inc.
餂?/div>
2002
Port 3
Port 2
Port 1
ADC
Port 0
9.2002; Rev. 1.2

C8051F206 產品屬性

  • 250

  • 集成電路 (IC)

  • 嵌入式 - 微控制器，

  • C8051F2xx

  • 8051

  • 8-位

  • 25MHz

  • SPI，UART/USART

  • 欠壓檢測/復位，POR，WDT

  • 32

  • 8KB（8K x 8）

  • 閃存

  • -

  • 1.25K x 8

  • 2.7 V ~ 3.6 V

  • A/D 32x12b

  • 內部

  • -40°C ~ 85°C

  • 48-TQFP

  • 托盤
