-5kV
REGULATED HIGH VOLTAGE
POWER SUPPLY
C3360
-5kV Regulated Power Supply
For MCP-PMT, Electron Multiplier, MCP, etc.
Hamamatsu C3360 is a highly regulated bench-top
power supply with -5kV, 1mA output. It is designed
especially for operations of microchannel plate
incorporated photomultipliers (MCP-PMT), electron
multipliers, and microchannel plates (MCP). The LED
panel meter on the front panel allows easy and
precise voltage monitoring.
TACCF0078
Specifications
Parameter
Output Voltage
Maximum Output Current
Line Regulation Against
鹵10%
Line Voltage Change
Load Regulation Against 0 to 100% Load Change
Ripple/Noise
Drift (after 1h Warm-up)
Temperature Coefficient
Output Voltage Monitor
Output Voltage Monitoring Accuracy
Protection Circuit
Input Voltage
Power Consumption
Operating Temperature/Humidity
Specification Guaranteed Temperature/Humidity
Storage Temperature/Humidity
Output Receptacles
Weight
NOTE
At maximum output voltage and current.
At maximum output voltage.
Without moisture condensation.
Description/Value
0 to -5000Vdc
1mA
鹵
(0.001% +0.05V) Max.
鹵
(0.001% +0.05V) Max.
0.0004% p-p Max.
鹵0.05%/8h
Max.
鹵0.01%/擄C
Max.
4-digit digital meter
鹵
(0.2%+2V) Max.
For short circuit and excess output current
85 to 132Vac/170 to 264 Vac
Approx. 21VA
0 to +40擄C / 90% RH Max.
+5 to +35擄C / 85% RH Max.
-20 to +50擄C / 90% RH Max.
Two SHV receptacles
3.5kg
Accessories
AC line cable (2.4m long) 路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路 1
High voltage output cable (1.5m long) terminated with SHV-P plugs E1168-19 路路路路路路路路路路路 1
Spare fuses 路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路 2
