鹵3kV
REGULATED HIGH VOLTAGE
POWER SUPPLY
C3350
鹵3kV
Output Regulated DC Power Supply
For Photomultiplier Tube, Proportional Counter Tube, etc.
Hamamatsu C3350 is a highly regulated bench-top
power supply with
鹵3kV,
10mA output. The LED
panel meter on the front panel allows easy and
precise voltage monitoring. It is especially suited for
laboratory uses including photomultiplier and
proportional counter tube operations.
TACCF0075
Specifications
Parameter
Output Voltage
Specification Guaranteed Output Voltage
Maximum Output Current
Line Regulation Against
鹵10%
Line Voltage Change
Load Regulation Against 0 to 100% Load Change
Ripple/Noise
Drift (after 1h Warm-up)
Temperature Coefficient
Output Voltage Monitor
Output Voltage Monitoring Accuracy
Protection Circuit
Input Voltage
Power Consumption
Specification Guaranteed Temperature/Humidity
Storage Temperature/Humidity
Output Receptacles
Weight
NOTE
At maximum output voltage and current.
At maximum output voltage.
Without moisture condensation.
Description/Value
0 to
鹵3000Vdc
鹵250
to
鹵3000Vdc
10mA
鹵
(0.005%+10mV ) Max.
鹵
(0.01%+50mV) Max.
0.0007% p-p Max.
鹵
(0.02%+10mV) /8h Max.
鹵0.01%/擄C
Max.
4-digit digital meter
鹵
(0.1%鹵3V) Max.
For short circuit and excess output current
100/115/220/230 Vac
鹵10%,
50/60Hz
Approx. 100VA
+5 to +35擄C / 85% RH Max.
-20 to +50擄C / 95% RH Max.
Two SHV receptacles
8kg
Accessories
AC line cable (2.4m long) 路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路 1
High voltage output cable (1.5m long) terminated with SHV-P plugs E1168-19 路路路路路路路路路路路 1
Spare fuses 路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路路 2
Subject to local technical requirements and regulations, availability of products included in this promotional material may vary. Please consult with our sales office.
Information furnished by HAMAMATSU is believed to be reliable. However, no responsibility is assumed for possible inaccuracies or omissions. Specifications are
subject to change without notice No patent right are granted to any of the circuits described herein. 漏 1998 Hamamatsu Photonics K.K.
