Upconverters
Description
The C2304 is a flexible high intercept and high gain down conversion GaAs MMIC packaged in a compact 14
pin SOIC package. Each sub-circuit is brought out on separate pins to allow for custom filtering on the IF/RF
mixer interstage or custom matching for specific bands. Broadband parallel feedback networks are used on the
gain and LO driver stages and the mixer is a singly balanced, two diode type mixer. The FET source of the IF
amplifier stage (IF BIAS) is accessible for AC bypassing which allows for current reduction with DC source
degeneration. The gain and DC current is broken up as follows: RF AMP gain = 14dB, current = 22 mA; LO
AMP gain = 11dB, current = 28ma; IF AMP gain = 18dB, current = 60 mA, MIXER conversion loss = -6dB.
Simple external matching circuits can be implemented for all ports to achieve VSWR鈥檚 <2:1 over moderate
bandwidths of less than 400MHz.
Electrical Characteristics
Typical Specifications for V
DD
=5.0V T
A
=+25
o
C
Minimum and Maximum specifications are guaranteed over RF range 2.5GHz 鈥?2.68GHz
Tested in 50鈩?input / 75鈩?output system, LO=2.278GHz at 5dBm, using matching circuit shown on page 3.
Parameter
Conversion Gain
Single Sideband Noise Figure
Output IP3
RF Input Return Loss
IF Output Return Loss
Symbol
G
NF
IP3
S
11
S
22
Conditions
LO=5dBm
LO=2.278GHz
LO=5dBm
50鈩?input ref.
75鈩?output ref.
Min
24.7
Typ
26
4
27
-12
-11
Max
27.3
Units
dB
dB
dBm
dB
dB
1
2
3
4
