BZT52-C2V4 THRU BZT52-C75

ZENER DIODES

FEATURES

SOD-123

.022 (0.55)

鈾?/div>

Silicon Planar Power Zener Diodes

鈾?/div>

The Zener voltages are graded according to the international

E 24 standard. Standard Zener voltage tolerance

is 鹵5%. Replace suffix 鈥淐鈥?with 鈥淏鈥?for 鹵2% toler-

ance. Other tolerances and other Zener voltages

are available upon request.

鈾?/div>

These diodes are also available in other case styles and other

configurations including: the SOT-23 case with type designation

BZX84 series, the dual zener diode common anode configuration

in the SOT-23 case with type designation AZ23 series and the

dual zener diode common cathode configuration in the SOT-23

case with type designation DZ23 series.

Cathode Mark

.152 (3.85)

.140 (3.55)

.112 (2.85)

.100 (2.55)

Top View

max. .004 (0.1)

max. .053 (1.35)

min. .010 (0.25)

max. .006 (0.15)

.067 (1.70)

.055 (1.40)

MECHANICAL DATA

Dimensions are in inches and (millimeters)

Case:

SOD-123 Plastic Case

Weight:

approx. 0.01 g

MAXIMUM RATINGS

Ratings at 25擄C ambient temperature unless otherwise specified.

SYMBOL

VALUE

UNIT

Zener Current (see Table 鈥淐haracteristics鈥?

Power Dissipation at Tamb = 25擄C

Junction Temperature

Storage Temperature Range

tot

410

(1)

150

鈥?65 to +150

擄C

SYMBOL

MIN.

TYP.

MAX.

UNIT

Thermal Resistance

Junction to Ambient Air

螛JA

鈥?/div>

300

(2)

擄C/W

NOTES:

(1) Diode on Ceramic Substrate 0.7mm; 2.5mm

area

(2) Valid provided that electrodes are kept at ambient temperature

12/10/98
