BYV32-200/D Datasheet

  • BYV32-200/D

  • SWITCHMODE Power Rectifier

  • 4頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

BYV32鈭?00
SWITCHMODE鈩?/div>
Power Rectifier
. . . designed for use in switching power supplies, inverters and as
free wheeling diodes, this state-of-the-art device has the following
features:
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Ultrafast 35 Nanosecond Recovery Time
175擄C Operating Junction Temperature
Popular TO-220 Package
Epoxy Meets UL94, V
O
@ 1/8鈥?/div>
High Temperature Glass Passivated Junction
Low Leakage Specified @ 150擄C Case Temperature
Current Derating @ Both Case and Ambient Temperatures
http://onsemi.com
ULTRAFAST
RECTIFIER
16 AMPERES
200 VOLTS
1
2, 4
3
Mechanical Characteristics:
鈥?/div>
Case: Epoxy, Molded
鈥?/div>
Weight: 1.9 grams (approximately)
鈥?/div>
Finish: All External Surfaces Corrosion Resistant and Terminal
Leads are Readily Solderable
鈥?/div>
Lead Temperature for Soldering Purposes:
260擄C Max. for 10 Seconds
鈥?/div>
Shipped 50 units per plastic tube
鈥?/div>
Marking: BYV32-200
MAXIMUM RATINGS
Rating
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Average Rectified Forward Current
Total Device, (Rated V
R
), T
C
= 150擄C
Per Leg
Total Device
Peak Rectified Forward Current
(Rated V
R
, Square Wave, 20 kHz),
T
C
= 150擄C - Per Diode Leg
Nonrepetitive Peak Surge Current
(Surge applied at rated load conditions
halfwave, single phase, 60 Hz)
Operating Junction Temperature and
Storage Temperature
Symbol
V
RRM
V
RWM
V
R
I
F(AV)
8.0
16
I
FM
16
Amps
Value
200
Unit
Volts
1
2
3
4
MARKING DIAGRAM
BYV32
-200
Amps
TO-220AB
CASE 221A
PLASTIC
BYV32-200 = Device Code
ORDERING INFORMATION
Device
Package
TO-220
Shipping
50 Units/Rail
I
FSM
100
Amps
BYV32-200
T
J
, T
stg
-65 to
+175
擄C
漏
Semiconductor Components Industries, LLC, 2002
1
November, 2002 - Rev. 0
Publication Order Number:
BYV32-200/D
