10BIT 30MSPS TRIPLE DAC

BW1221L_3CLK

GENERAL DESCRIPTION

The BW1221L_3CLK is a CMOS Triple

10Bit D/A converter for general &

video applications.

Its typical conversion rate is 30MSPS

(maximum 50MSPS) and supply voltage is

3.3V single. An external 1.0V voltage

reference(VREF) and a single resistor

(RSET) control the full_scale output current.

TYPICAL APPLICATIONS

.

.

.

.

.

.

.

High Definition Television(DTV,HDTV)

High Resolution Color Graphics

Hard Disk Driver(HDD)

CAE/CAD/CAM

Image Processing

Instrumentation

Conventional Digital to Analog Conversion

FUNCTIONAL BLOCK DIAGRAM

Second Latch 1

Fi rst Latch1

SWITCH 1

Decoeder 1

D1[9:0]

IO1

Second Latch 2

Fi r st Latch2

SWI TCH 2

Decoeder 2

D2[9:0]

IO2

FEATURES

Second Latch 3

Fi rst Latch3

.

.

.

.

.

.

.

.

.

.

30MSPS 1CLK pipeline delay operation

+3.3V CMOS monolothic construction

1.0LSB differential linearity error(Max)

鹵

2.5LSB integral linearity error(Max)

鹵

External voltage reference

Triple Channel DAC

10-Bit voltage parallel input per channel

High impedance single current output

Bineary coding input

High impedance analog output current

source

SWI TCH 3

Decoeder 3

D3[9:0]

IO3

COMP

CLK1

OPA

CLK2

CLK3

CM

CLKGEN

VREF

PD IREF

Ver 1.0 (Mar. 1999)

No responsibility is assumed by SEC for its use nor for any

infringements of patents or other rights of third parties that may

result from its use. The content of this datasheet is subject to

change without any notice.

SEC ASIC

1 / 11
