12BIT 10MSPS DAC

GENERAL DESCRIPTION

The BW1219A is a CMOS 12Bit D/A converter for

general application.

This digital to analog converter consists of a R-2R

ladder block and an Op amp block.

Its maximum conversion rate is 10MSPS.

BW1219A

FEATURES

鈥?Resolution : 12Bits

鈥?Differential Linearity Error :

鹵1.0

LSB(MAX)

鈥?Maximum Conversion Rate : 10MSPS

鈥?Supply Voltage : 3.3V

鈥?External Voltage Reference : 0.1V, 2.1V

鈥?Output Swing : 0.1V - 2.1V

鈥?Operation Temperature Range : 0潞C - 70潞C

TYPICAL APPLICATIONS

鈥?HDD

鈥?General purpose Digital to Analog Converter

FUNCTIONAL BLOCK DIAGRAM

VRT

D[11:0]

VRB

R2R

LADDER

OP

AMP

VOUT

Ver 1.2 (Feb,2000)

No responsibility is assumed by SEC for its use nor for any

infringements of patents or other rights of third parties that may

result from its use. The content of this datasheet is subject to

change without any notice.

SAMSUNG ELECTRONICS Co. LTD

1/11
