BUT11AF/D Datasheet

  • BUT11AF/D

  • Full Pak High Voltage NPN Power Transistor

  • 59.72KB

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

ON Semiconductort
FULL PAKt
High Voltage NPN Power Transistor
For Isolated Package Applications
The BUT11AF was designed for use in line operated switching
power supplies in a wide range of end use applications. This device
combines the latest state of the art bipolar fabrication techniques to
provide excellent switching, high voltage capability and low
saturation voltage.
BUT11AF
POWER TRANSISTOR
5.0 AMPERES
450 VOLTS
40 WATTS
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
1000 Volt V
CES
Rating
Low Base Drive Requirements
Isolated Overmold Package
Improved System Efficiency
No Isolating Washers Required
Reduced System Cost
High Isolation Voltage Capability (4500 V
RMS
)
CASE 221D鈥?2
TO鈥?20 TYPE
MAXIMUM RATINGS
Rating
Collector鈥揈mitter Sustaining Voltage
Collector鈥揈mitter Breakdown Voltage
Emitter鈥揃ase Voltage
RMS Isolation Voltage (For 1 sec,
T
A
= 25擄C, Rel. Humidity < 30%)
Per Figure 7
Per Figure 8
Per Figure 9
Collector Current 鈥?Continuous
Collector Current
鈥?Pulsed (1)
Base Current 鈥?Continuous
Base Current
鈥?Pulsed (1)
Total Power Dissipation @ T
C
= 25擄C*
Derated above 25擄C
Operating and Storage Temperature Range
Symbol
V
CEO(sus)
V
CES
V
EBO
V
ISOL1
V
ISOL2
V
ISOL3
I
C
I
CM
I
B
I
BM
P
D
T
J
, T
stg
Value
450
1000
9.0
4500
3500
2500
5.0
10
2.0
4.0
40
0.32
鈥?65 to +150
Adc
Adc
Watts
W/擄C
擄C
V
Unit
Vdc
Vdc
Vdc
THERMAL CHARACTERISTICS
Thermal Resistance 鈥?Junction to Case*
Maximum Lead Temperature for soldering purposes
1/8鈥?from case for 5 sec.
(1) Pulse Test: Pulse Width = 5.0 ms, Duty Cycle
鈮?/div>
10%.
*Measurement made with thermocouple contacting the bottom insulated mounting surface of the package (in a location beneath the die),
the device mounted on a heatsink, thermal grease applied, and a mounting torque of 6 to 8 in
.
lbs.
R
胃JC
T
L
3.125
260
擄C/W
擄C
漏
Semiconductor Components Industries, LLC, 2001
1
March, 2001 鈥?Rev. 4
Publication Order Number:
BUT11AF/D
