BULD1101ET4 Datasheet

  • BULD1101ET4

  • HIGH VOLTAGE FAST-SWITCHING NPN POWER TRANSISTOR

  • 7頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
BULD1101ET4
HIGH VOLTAGE FAST-SWITCHING
NPN POWER TRANSISTOR
PRELIMINARY DATA
Ordering Code
BULD1101ET4
s
s
s
Marking
BULD1101E
Shipment
Tape & Reel
s
s
s
HIGH VOLTAGE CAPABILITY
LOW SPREAD OF DYNAMIC PARAMETERS
MINIMUM LOT-TO-LOT SPREAD FOR
RELIABLE OPERATION
VERY HIGH SWITCHING SPEED
LARGE RBSOA
SURFACE-MOUNTING DPAK (TO-252)
POWER PACKAGE IN TAPE & REEL
(SUFFIX "T4")
3
1
DPAK
TO-252
(Suffix "T4")
APPLICATIONS
s
ELECTRONIC BALLASTS FOR
FLUORESCENT LIGHTING
DESCRIPTION
The device is manufactured using High Voltage
Multi Epitaxial Planar technology for high
switching speeds and high voltage capability. It
uses a Cellular Emitter structure with planar edge
termination to enhance switching speeds while
maintaining a wide RBSOA.
INTERNAL SCHEMATIC DIAGRAM
ABSOLUTE MAXIMUM RATINGS
Symbol
V
CES
V
CEO
V
EBO
I
C
I
CM
I
B
I
BM
P
tot
T
stg
T
j
Parameter
Collector-Emitter Voltage (V
BE
= 0)
Collector-Emitter Voltage (I
B
= 0)
Emitter-Base Voltage (I
C
= 0)
Collector Current
Collector Peak Current (t
p
<5 ms)
Base Current
Base Peak Current (t
p
<5 ms)
Total Dissipation at Tc = 25
o
C
Storage Temperature
Max. Operating Junction Temperature
Value
1100
450
12
3
6
1.5
3
35
-65 to 150
150
Unit
V
V
V
A
A
A
A
W
o
o
C
C
April 2003
1/7

BULD1101ET4 產品屬性

  • STMicroelectronics

  • Transistors Bipolar (BJT)

  • NPN

  • 450 V

  • 12 V

  • 3 A

  • 20

  • + 150 C

  • SMD/SMT

  • DPAK

  • Reel

  • 35000 mW

  • 2500
