TrilithIC鈩?/div>

BTS 775 G

Overview

Features

鈥?/div>

Quad switch driver

Free configurable as bridge or quad-switch

Optimized for DC motor management applications

Ultra low

DS ON

@ 25

擄C:

High-side switch: typ.85 m鈩?

P-DSO-28-9

Low-side switch: typ. 45 m鈩?/div>

Very high peak current capability

Very low quiescent current

Space- and thermal optimized power P-DSO-Package

Full short-circuit-protection

Operates up to 40 V

Status flag diagnosis

Overtemperature shut down with hysteresis

Short-circuit detection and diagnosis

Open-load detection and diagnosis

C-MOS compatible inputs

Internal clamp diodes

Isolated sources for external current sensing

Over- and under-voltage detection with hysteresis

Ordering Code

Q67007-A9350

Package

P-DSO-28-9

鈥?/div>

Type

BTS 775 G

Description

The

BTS 775 G

is a

TrilithIC

contains one double high-side switch and two low-side

switches in

one P-DSO-28-9

-Package.

鈥淪ilicon instead of heatsink鈥?/div>

becomes true

The ultra low

DS ON

of this device avoids powerdissipation. It saves costs in mechanical

construction and mounting and increases the efficiency.

The high-side switches are produced in the

SIEMENS SMART SIPMOS

廬

technology. It

is fully protected and contains the signal conditioning circuitry for diagnosis. (The

comparable standard high-side product is the

BTS 621L1.)

Semiconductor Group

1999-01-07
