Optoway
BTR-7660G / BTR-7660-SPG
FEATURES
l
l
l
l
l
l
l
l
l
l
l
l
l
BTR-7660G
1
***********************************************************************************************************************************************************************
1310 nm TX / 1550 nm RX , 3.3V / 1.25 Gb/s
RoHS Compliant
Single-Fiber Transceiver
**********************************************************************************************************************************************************************
DESCRIPTION
Single Fiber Bi-Directional Transceiver
1310 nm DFB LD Transmitter
1550 nm Receiver
Link distance up to 60 km
Industry Standard 1 x 9 Footprint
Single +3.3 V Power Supply
RoHS Compliant
0 to 70
o
C Operating
LVPECL Differential Inputs and Outputs
LVPECL Signal Detect Output: BTR-7660G
LVTTL Signal Detect Output: BTR-7660CG
Wave Solderable and Aqueous Washable
Class 1 Laser International Safety Standard IEC-60825
Compliant
The BTR-7660G series is high performance module for
single fiber communications by using 1310 nm transmitter
and 1550 nm receiver. The transmitter section uses a
multiple quantum well 1310 nm DFB laser and is a class 1
laser compliant according to International Safety Standard
IEC-60825. The receiver section uses an integrated 1550
nm detector preamplifier (IDP) mounted in an optical
header and a limiting post-amplifier IC. A PECL logic
interface simplifies interface to external circuitry.
LASER SAFETY
This single mode transceiver is a Class 1 laser product. It
complies with IEC-60825 and FDA 21 CFR 1040.10 and
1040.11. The transceiver must be operated within the
specified temperature and voltage limits. The optical ports
of the module shall be terminated with an optical connector
or with a dust plug.
APPLICATIONS
l
WDM 1.25 Gb/s Links
l
SONET/SDH Equipment Interconnect
l
Fibre Channel 1.063 Gb/s Links
ORDER INFORMATION
P/No.
Bit
Rate
(Gb/s)
1.25
1.25
Distance
(km)
TX
(nm)
RX
(nm)
Voltage
(V)
Package
Temp
( C)
o
TX
Power
(dBm)
RX
Sens.
(dBm)
Signal
Detect
RoHS
Compliant
BTR-7660CG
BTR-7660G
60
60
1310DFB
1310DFB
1550
1550
3.3
3.3
1X9
1X9
0 to 70
0 to 70
4 to -1
4 to -1
-26
-26
TTL
PECL
Yes
Yes
Note: 1. BTR-XXXXX is 1X9 SC receptacle type package.
2. BTR-XXXXX-APBBB is 1X9 pigtail type package with different connector, A=S is SC connector, A=F is FC
connector, A=T is ST connector, A=L is LC connector, A=M is MU connector; BBB is the length of fiber in cm.
Absolute Maximum Ratings
Parameter
Storage Temperature
Operating Temperature
Soldering Temperature
Power Supply Voltage
Input Voltage
Output Current
Symbol
Tstg
Topr
---
Vcc
---
Iout
Min
-40
0
0
GND
0
Max
85
70
260
4.5
Vcc
30
Units
o
C
o
C
o
C
V
V
mA
Notes
10 seconds on leads only
Recommended Operating Conditions
Parameter
Power Supply Voltage
Operating Temperature
Data Rate
Power Supply Current
Symbol
Vcc
Topr
Icc
Min
3.13
0
Typ
3.3
1250
Max
3.47
70
1300
280
Units
V
o
C
Mb/s
mA
***********************************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax: 886-3-5979737
E-mail: sales@optoway.com.tw http: // www.optoway.com.tw
10/1/2005 V2.0
