BPV23NF(L)
Vishay Telefunken
Silicon PIN Photodiode
Description
BPV23NF(L) is a high speed and high sensitive PIN
photodiode in a plastic package with a spherical side
view lens.
The epoxy package itself is an IR filter, spectrally
matched to GaAs on GaAs and GaAlAs on GaAlAs IR
emitters (
l
p
= 950 nm, s
rel
(
l
= 875 nm) > 90 %).
Lens radius and chip position are perfectly matched to
the chip size, giving high sensitivity without
compromising the viewing angle.
In comparison with flat packages the spherical lens
package achieves a sensitivity improvement of 80%.
94 8633
Features
D
D
D
D
D
D
D
Large radiant sensitive area (A = 5.7 mm
2
)
Wide viewing angle
蠒
=
鹵
60
擄
Improved sensitivity
Fast response times
Low junction capacitance
Plastic package with universal IR filter
Option 鈥滾鈥? long lead package optional available
with suffix 鈥滾鈥? e.g.: BPV23FL
Applications
Infrared remote control and free air transmission systems in combination with IR emitter diodes
(TSU.鈥? TSI.鈥? or TSH.鈥揝eries). High sensitivity detector for high data rate transmission systems.
The IR filter matches perfectly to the high speed infrared emitters in the 830 nm to 880 nm wavelength range.
Absolute Maximum Ratings
T
amb
= 25
_
C
Parameter
Reverse Voltage
Power Dissipation
Junction Temperature
Operating Temperature Range
Storage Temperature Range
Soldering Temperature
Thermal Resistance Junction/Ambient
Test Conditions
T
amb
Symbol
V
R
P
V
T
j
T
amb
T
stg
T
sd
R
thJA
Value
60
215
100
鈥?5...+100
鈥?5...+100
260
350
Unit
V
mW
擄
C
擄
C
擄
C
擄
C
K/W
x
25
擄
C
t
x
5s
Document Number 81513
Rev. 3, 16-Nov-99
www.vishay.de
鈥?/div>
FaxBack +1-408-970-5600
1 (6)
