AC/DC converter
AC100V input, -15V/800mA output
BP5068-15
Absolute Maximum Ratings
Parameter
Input voltage
Output current
ESD endurance
Operating temperature range
Storage temperature range
Symbol
Vi
Io
Vsurge
Topr
Tstg
Limits
-190
800
2
-20
to +80
-25
to +105
Unit
V
mApk
kV
擄C
擄C
Dimension(Unit : mm)
34.5MAX.
Mark Side
1
3
5
7 8
10
12
0 . 2 5
鹵
0 . 0 5
P=2.54
鹵
0.2
7.35MAX.
3.95MAX.
0 . 5
鹵
0 . 1
3.25MAX
1 . 3
鹵
0 . 2
2.54 11=27.94
11.3MAX.
4
鹵
1.0
21.5MAX.
+
Electrical Characteristics
Parameter
Symbol Min.
Input voltage range
Vi
-162
Output voltage
Vo
-16
Output current
Io
0
Line regulation
Vr
-
Load regulation
Vl
-
Output ripple voltage
Vp
-
Power conversion effciency
h
80
Typ.
-141
-15
-
0.20
0.50
0.15
85
Max.
-120
-14
800
0.45
0.75
0.30
-
Unit
V
V
mA
V
V
Vp-p
%
Conditions
DC(85 to 115VAC)
Vi=
-141V,
Io=800mA
*1
Vi=
-141V
Vi=
-120
to
-162V,
Io=800mA
Vi=
-141V,
Io=0 to 800mA
*2
Vi=
-141V,
Io=800mA
Vi=
-141V,
Io=800mA
*2
Derating Curve
Derating Curve
1.0
0.9
0.8
0.7
0.6
0.5
Operation Range
0.4
0.3
0.2
0.1
0
-30 -20 -10 0 10 20 30 40 50 60 70 80 90
Ambient Temperature Ta(
擄C
)
Output Current Io(A)
*
1 Maximum output current varies depending on ambient temperature ; please refer to derating curve.
*
2 Please refer to Load regulation, Conversion effciency.
Conversion Efficiency
Conversion Efficiency
h(%)
100
80
60
40
20
0
0
200
400
600
Output Current Io(mA)
800
Conversion Efficiency
(Ta=25
擄C
, Vi=
-
141V)
Application circuit
BP5068-15
Please note that pin No.12
side is input.
12 10
R1
D2
1SR35-400A 2.2 1/4W
Input
AC100V
50Hz/60Hz
ZNR
C1
220V
+
100mF/200V
-
FUSE
2A
C2
0.1mF
8 7
5
3
1
L1
470mH
D1
-
C3
+
470mF/50V
Be sure to use fuse for safety.
For acutual usage, Please kindly evaluate and confirm our part mounted in your product,
Especially, Please make sure to confirm the load current does not exceed Max. rated current
by using the current probe.
External components setting
FUSE: Fuse
C1: Capacitor for input
voltage smoothing
C2: For noise terminal
voltage reduction
C3: Capacitor for Output
voltage smooting
D1: Flywheel diode
Please make sure to use quick acting fuse 2A
Capacitance : 47mF to 220mF Rated voltage : 200V or higher
Ripple current is 0.22Arms above.
Capacitance : 0.1mF to 0.22碌F Rated voltage : 200V or higher
Film capacitor or ceramic capacitor. Reduce the noise terminal voltage.
The constant value should be evaluated in the set.
Capacitance : 330mF to 1000碌F Rated voltage : 25V or higher,
ESR is 0.08 max. Ripple current is 1Arms above.
Output noise voltage is influenced,Please evaluate it in the actual set.
Please use the first recovery diode that reverse peak voltage is 400V or
higher, and the avarage rectifying current is 3A or higher.That switching
characteristic and efficiency of our module is influenced by this diode
characteristic, please use 31DF4(Nihon inter), or RV30(Sanken).
In the absolute maximum ratings, the reverse peak voltage should be
400V or higher, the average rectifying current should be 1A or higher,
and the peak surge current should be 20A or higher.
(Full-wave rectifier can be used in our part.)
Coil for switching regulator. The inductance should be 470mH,
the rated direct current should be 1.6A above. Otherwise heating or
abnormal oscilation occurs.
1.0 to 2.2 1/4W
Reduce the noise terminal voltage.The constant value should be evaluated
in set.
Varistor must be used. It protects this part from lightning surge and static
electricity.
Output Voltage Vo(V)
Output
-15V
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
Function
Output terminal Vo(-15V)
Not used
Coil connect
Not used
Coil connect
Not used
COMMON
COMMON
Not used
N.C.
Not used
Input terminal Vi(-141VDC)
Load Regulation
16.0
15.8
15.6
15.4
15.2
15.0
14.8
14.6
14.4
14.2
14.0
Load Regulation
(Ta=25
擄C
, Vi=
-
141V)
0
200
400
600
Output Current Io(mA)
800
Surface Temperature Rising
40
35
30
25
20
15
10
5
0
0
Surface Temperature Rising
(Ta=25
擄C
, Vi=
-
141V)
Temperature Rising T(
擄C)
200
400
600
Output Current Io(mA)
800
D2: Rectifier diode
L1: Choke coil
R1: For noise terminal
voltage reduction
ZNR: Varistor
