C1
C2
Vo
For acutual usage, Please kindly evaluate and confirm our part mounted in your product,
Especially, Please make sure to confirm whether the load current exceed Max. rated current
by using the current probe.
External components setting
Temperature Rising
鈭員(
擄C
)
0
50 100 150 200 250 300 350 400
Output Current Io(mA)
Surface Temperature Rising
FUSE: Fuse
C1: Capacitor for input
voltage smoothing
C2: Capacitor for Output
voltage smooting
C3: For noise terminal
voltage reduction
L1: Choke coil
Please make sure to use quick acting fuse 1A
Capacitance : 22碌F鈭?20碌F Rated voltage : 200V or higher
Ripple current is 0.13Arms above.
Capacitance : 100碌F鈭?70碌F Rated voltage : 25V or higher,
ESR is 0.4鈩?max. Ripple current is 0.25Arms above.
Output noise voltage is influenced.Please evaluate it in the actual set.
Capacitance : 0.1碌F鈭?.22碌F Rated voltage : 200V or higher
Film capacitor or ceramic capacitor. Reduce the noise terminal voltage.
The constant value should be evaluated in the set.
L : 1mH Allowable current : 600mA or higher
Please use the one that is hard to be magnetic saturated even in the high
temperature.
In the absolute maximum ratings, the reverse peak voltage should be
400V or higher, the average rectifying current should be 0.5A or higher,
and the peak surge current should be 20A or higher.
(Full-wave rectifier can be used in out part.)
10鈩︹埣22鈩?1/4W
Reduce the noise terminal voltage.Please set it,if necessary.
The constant value should be evaluated in set.
Varistor must be used. It protects this part from lightning surge and static
electricity.
40
35
30
25
20
15
10
5
0
Surface Temperature Rising
(Ta=25
擄C
, Vi=141V)
0
50 100 150 200 250 300 350
Output Current Io(mA)
D1: Rectifier diode
R1: For noise terminal
voltage reduction
ZNR: Varistor
