鈭?/div>
330碌F/25V
Be sure to use fuse for safety.
For acutual usage, Please kindly evaluate and confirm our part mounted in your product,
Especially, Please make sure to confirm whether the load current exceed Max. rated current
by using the current probe.
External components setting
50
100
150
Output Current Io(mA)
200
Load Regulation
Output Voltage Vo(V)
FUSE: Fuse
C1: Capacitor for input
voltage smoothing
C2: For noise terminal
voltage reduction
C3: Capacitor for Output
voltage smooting
D1: Rectifier diode
Please make sure to use quick acting fuse 1A
Capacitance : 22碌F~100碌F Rated voltage : 200V or higher
Ripple current is 0.13Arms above.
Capacitance : 0.1碌F~0.22碌F Rated voltage : 200V or higher
Film capacitor or ceramic capacitor. Reduce the noise terminal voltage.
The constant value should be evaluated in the set.
Capacitance : 100碌F~470碌F Rated voltage : 25V or higher,
ESR is 0.25鈩?max. Ripple current is 0.4Arms above.
Output noise voltage is infulenced.Please evaluate it in the actual set.
In the absolute maximum ratings, the reverse peak voltage should be
400V or higher, the average rectifying current should be 0.5A or higher,
and the peak surge current should be 20A or higher.
(Full-wave rectifier can be used in out part.)
Coil for switching regulator. The inductance should be 820碌H,
the rated direct current should be 0.42A above.
Otherwise heating or abnormal oscilation occurs.
10鈩22鈩?1/4W
Reduce the noise terminal voltage.Please set it,if necessary.
The constant value should be evaluated in set.
Varistor must be used. It protects this part from lightning surge and static
electricity.
5.3
5.2
5.1
5.0
4.9
4.8
4.7
0
Load Regulation
(Ta=25擄C, Vi=141V)
50
100
150
Output Current Io(mA)
200
Surface Temperature Rising
40
35
30
25
20
15
10
5
0
Temperature Rising
鈭員(擄C)
Surface Temperature Rising
(Ta=25擄C, Vi=141V)
L1: Choke coil
R1: For noise terminal
voltage reduction
ZNR: Varistor
0 20 40 60 80 100 120 140 160 180 200
Output Current Io(mA)
1/2
1
2
3
