External components setting
FUSE: Fuse
C1: Capacitor for input
voltage smoothing
C2: For noise terminal
voltage reduction
C3: Capacitor for Output
voltage smooting
D1: Rectifier diode
Please make sure to use quick acting fuse 1A
Capacitance : 22碌F Rated voltage : 200V or higher
Ripple current is 0.13Arms above.
Capacitance : 0.1碌F鈭?.22碌F Rated voltage : 200V or higher
Film capacitor or ceramic capacitor. Reduce the noise terminal voltage.
The constant value should be evaluated in the set.
Capacitance : 100碌F鈭?70碌F Rated voltage : 25V or higher,
ESR is 0.4鈩?max. Ripple current is 0.25Arms above.
Output noise voltage is infulenced. Please evaluate it in the actual set.
In the absolute maximum ratings, the reverse peak voltage should be
400V or higher, the average rectifying current should be 0.5A or higher,
and the peak surge current should be 20A or higher.
(Full-wave rectifier can be used in out part.)
Coil for switching regulator. The inductance should be 470碌H,
the rated direct current should be 0.7A above.
Otherwise heating or abnormal oscilation occurs.
10鈩︹埣22鈩?1/4W
Reduce the noise terminal voltage.The constant value should be evaluated
in set.
Varistor must be used. It protects this part from lightning surge and static
electricity.
Surface Temperature Rising
50
45
40
35
30
25
20
15
10
5
0
Temperature Rising
鈭員(
擄C
)
Surface Temperature Rising
(Ta=25
擄C
, Vi=鈭?41V)
0
50 100 150 200 250 300 350 400
Output Current Io(mA)
L1: Choke coil
R1: For noise terminal
voltage reduction
ZNR: Varistor
