Be sure to use fuse for safety.
For acutual usage, Please kindly evaluate and confirm our part mounted in your product,
Especially, Please make sure to confirm whether the load current exceed Max. rated current
by using the current prove.
鈭?/div>
T(
擄C
)
Surface Temperature Rising
FUSE: Fuse
C1: Capacitor for input
voltage smoothing
C2: For noise terminal
voltage reduction
C3: Capacitor for Output
voltage smooting
D1: Rectifier diode
Please make sure to use quick acting fuse 0.5A
Capacitance : 3.3碌F to 22碌F Rated voltage : 250V or higher
Ripple current is 0.13Arms above.
Capacitance : 0.1碌F to 0.22碌F Rated voltage : 250V or higher
Film capacitor or ceramic capacitor. Reduce the noise terminal voltage.
The constant value should be evaluated in the set.
Capacitance : 100碌F to 470碌F Rated voltage : 25V or higher,
ESR is 0.39鈩?max. Ripple current is 0.1Arms above.
Output noise voltage is influenced.Please evaluate it in the actual set.
In the absolute maximum ratings, the reverse peak voltage should be
400V or higher, the average rectifying current should be 0.5A or higher,
and the peak surge current should be 20A or higher.
(Full-wave rectifier can be used in our part.)
10鈩?to 22鈩?1/4W
Reduce the noise terminal voltage.The constant value should be evaluated
in set.
Varistor must be used. It protects this part from lighting surge and static
electricity.
35
30
25
20
15
10
5
0
0
20
40
60
80
Output Current Io(mA)
100
Surface Temperature Rising
(Vin=141V)
R1: For noise terminal
voltage reduction
ZNR: Varistor
1/2
