BL0305 Digital Echo (Digital Delay)
Description
The BL0305 is a CMOS IC for generating echo to be added to the voice through a 鈥渒araoke鈥?microphone. It
is designed for the lowest price of models in the same series,and is suitable for application to the echo
generator of a radio cassette player, minicomponent stereo set, TV etc. Increased master clock frequency
assures highperformance short delay, enabling the IC to be used for digital surround ( Compatible with
M65844P).
Pin Assignment
LPF1 IN
LPF1 OUT
OP1 OUT
OP1 IN
CC1
CC2
GND
1
2
3
4
5
6
7
14
13
12
11
10
9
8
V
CC
CLOCK
REF
OP2 IN
OP2 OUT
LPF2 IN
LPF2 OUT
DIP 14 Pin
Features
銉籄ll
functions necessary for generating
digital echo are contained, enabling
production of low-priced echo generator.
銉籆-R
oscillation circuit is provided for a master clock,
銉籅uilt-in
auto power-on reset circuit.
銉籒o
control signal is required.
銉籇elay
time=150msec(with master clock set at 220 kHz)
銉?4-pin
DIP package.(14PDIP)
