BRIGHT LED ELECTRONICS CORP.
鈼?/div>
Features:
1. Chip material: AlInGaP/GaAs
2. Emitted color : Super Orange
3. Lens Appearance : Water Clear
4. Low power consumption.
5. High efficiency.
6. Versatile mounting on P.C. Board or panel.
7. Low current requirement.
8. 5mm diameter package.
9. This product don鈥檛 contained restriction
substance, compliance ROHS standard.
鈼?/div>
Package dimensions
5.0(.197)
4.50(.177)
8.6(.338)
1.0 (.04)
5.6(.220)
1.5(.059)
MAX.
25.4(1.0) MIN.
0.5(.02)
SQ. TYP.
FLAT DENOTES CATHODE
1.0(.04) MIN.
鈼?/div>
Applications:
1. TV set
2. Monitor
3. Telephone
4. Computer
5. Circuit board
Notes:
2.54(.10) NOM.
1. All dimensions are in millimeters (inches).
2. Tolerance is 鹵0.25mm (0.01鈥? unless otherwise specified.
3. Lead spacing is measured where the leads emerge from
the package.
4. Specifications are subject to change without notice.
鈼?/div>
Absolute maximum ratings(Ta=25鈩?
Parameter
Power Dissipation
Forward Current
Peak Forward Current*
1
Reverse
Voltage
Operating Temperature
Storage Temperature
Soldering Temperature
Symbol
Pd
I
F
I
FP
V
R
Topr
Tstg
Tsol
Rating
100
30
150
5
-40
鈩?/div>
~80
鈩?/div>
-40
鈩?/div>
~85
鈩?/div>
260
鈩?/div>
(for 5 seconds)
Unit
mW
mA
mA
V
*
1
Condition for I
FP
is pulse of 1/10 duty and 0.1msec width.
Ver.2.0 Page: 1 of 2
