BIM1 Datasheet

  • BIM1

  • VHF Narrow Band FM transceiver

  • 15頁

  • RADIOMETRIX

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

EW
N
Radiometrix
Hartcran House, 231 Kenton Lane, Harrow, HA3 8RP, England
Tel: +44 (0) 20 8909 9595, Fax: +44 (0) 20 8909 2233
Issue 3, 14 September 2007
BiM1, TX1H
VHF Narrow Band FM transceiver
The BiM1 transceiver modules offer a
100mW RF output VHF data link in
Radiometrix transceiver standard
pin-out and footprint. This makes the
BiM1 ideally suited to those low
power applications where existing
wideband
transceivers
provide
insufficient range.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Conforms to EN 300 220-3 and EN 301 489-3 (10mW version only)
Standard frequency 151.300MHz
Other frequencies from 120MHz to 180MHz
Available separately as BiM1T transmitter and BiM1R receiver
TX1H is a BiM1T in TX1 pin-out
Data rates up to 10kbps for standard module
Usable range over 10km
Fully screened
Feature-rich interface (RSSI, analogue and digital baseband
Low power requirements
Figure 1: BiM1-151.300-10
The BiM1 is a half duplex radio transceiver module for use in long range bi-directional data transfer
applications at ranges up to 10kilometres. The module operates on the UK licence exempt frequency of
173.225/173.250MHz with 10mW RF output and Australian frequency of 151.300MHz with 100mW RF
output. The small footprint of 23 x 33mm and low profile of 10mm together with low power
requirements of <80mA (for 100mW) at 3.8V enables convenient PCB installation. BiM1 is also
available as separate BiM1T transmitter and BiM1R receiver which can be used as dual-in-line
equivalents of TX1 transmitter and RX1 receiver respectively.
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
EPOS equipment, barcode scanners
Data loggers
Industrial telemetry and telecommand
In-building environmental monitoring and control
High-end security and fire alarms
DGPS systems
Vehicle data up/download
Technical Summary
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Size: 33 x 23 x 10mm
Operating frequency: 151.300MHz
Supply range: 100mW Transmitter 3.8V - 15V, Receiver: 3.0V-15V
Supply range: 10mW Transmitter 3.0V - 15V, Receiver: 3.0V-15V
Current consumption: 80mA transmit @ 100mW, 8mA receive
Data bit rate: 10kbps max. (standard module)
RSSI output with >60dBm range
10kbps, -120dBm sensitivity (for 12 dB SINAD)
BiM1 transceiver, TX1H high power transmitter data sheet
Page 1
Radiometrix Ltd.,
