Bidirectional 3.3 V I/O Transceiver

for SCSI-2, SCSI-3, and SCSI-3

Fast-20 Buses (LCBG10P)

Datasheet

LSI Logic鈥檚 bidirectional transceiver for SCSI is used to transmit and

receive data on a SCSI-2 or SCSI-3 bus. The bus operates at rates up

to 20 MHz, with a cable length up to 3 m and maximum stub lengths of

0.1 m. Implementations that limit transfer rates to 5 MHz can extend the

cable length to 6 m. SCSI bus termination is assumed to be external to

the SCSI device.

This transceiver conforms to the

Information Technology鈥擲CSI-3

Parallel Interface Speci鏗乧ation

as well as to the

American National

Standard for Information Systems鈥擲CSI-3 Fast-20,

published by the

X3T9.2 and X3T10 committees.

This transceiver can operate with SCSI-2, SCSI-3 10-MHz interfaces, or

SCSI-3 Fast-20 interfaces. These I/O cells operate at up to 20 MHz. This

transceiver is implemented in G10鈩?technology.

Figure 1

SCSI Bus Interface

PC or Workstation

SCSI

Controller

Termi-

nation

Termi-

nation

FP

O

1

2

3

4

5

6

7

Target Devices

April 1999

Copyright 漏 1997 by LSI Logic Corporation. All rights reserved.

1
