BH7801BK Datasheet

IC型號：
BH7801BK
PDF描述：
Single chip Hi-Fi audio signal processor
文件大小：
184.62KB
PDF頁數：
14頁
芯片廠家：
ROHM

閱覽下載糾錯 0

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Video ICs

Single chip Hi-Fi audio signal

processor

BH7801BK

The BH7801BK incorporates the functions for a VHS audio signal processing system on a single chip. The circuits

on the chip are a peak-noise reduction processor (PNR), an FM modulator / demodulator circuit, an I / O switcher, an

automatic FM detector circuit, an FM bandpass filter, and a regulator circuit.

鈥?/div>

Applications

VCRs

鈥?/div>

Features off dual 鹵 power supply which allows a

1) Operates

large reduction in the number of coupling capacitors

required. A built-in regulator makes it easy to con-

struct a power supply system.

2) A two-line I

C BUS control decoder circuit is provid-

ed, allowing the various IC modes to be set using

serial control.

3) A four line input switcher is included (tuner, BS, and

line 1 / 2). The output switcher can switch between

STREO, LEFT, and RIGHT, and Hi-Fi, MIX, and

NORMAL, and a BS MONITOR function is also pro-

vided.

4) The PNR processor and FM modulator / demodula-

tor circuit have reversed characteristics at recording

and playback. In addition, the adjustment for carrier

frequency and FM deviation / playback level are

common.

5) The built-in bandpass filter excels at attenuation of

other channels, and can be directly coupled to the

playback amplifier. The FM recording output block

has a high-performance low-pass filter to produce

sine wave output.

6) Slope-control-type FM-switching-noise compensa-

tion circuit.

7) Envelope detector circuit and noise-detector-type

automatic FM detector circuit.

8) VCO that uses the color signal sub-carrier frequency

(NTSC: 3.579545MHz, PAL: 4.433619MHz) and

auto-adjusting BPF circuit ensure stable adjustment

with no fluctuation due to mounting stress or time.

鈥?/div>

Absolute maximum ratings (Ta = 25擄C)

Parameter

Symbol

Applied voltage

Power dissipation

Operating temperature

Storage temperature

Topr

Tstg

Limits

18, 36pin

路路路路路路路路路路路路路路路路路路路路路路路

6.0

39pin

路路路路路路路路路路路路路路路路路路路路路路路路路

鈥?6.0

Unit

擄C

路路路路路路路路路路路路路路路路路路路路

6.5

Pins other than the above

路路路

6.0

5, 6, 32pin

850

鈭?/div>

鈥?10 ~ + 70

鈥?55 ~ + 125

鈭?/div>

Reduced by 8.5mW for each increase in Ta of 1擄C over 25擄C when mounted on a 70mm

脳

70mm, t = 1.6mm glass epoxy board.
