BH3541F Datasheet

  • BH3541F

  • Headphone amplifier for CD-ROMs

  • 8頁

  • ROHM

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

BH3541F / BH3544F
Optical disc ICs
Headphone amplifier for CD-ROMs
BH3541F / BH3544F
The BH3541F and BH3544F are digital-source dual headphone amplifiers. The BH3541F has a fixed gain of 0dB and
the BH3544F has a fixed gain of 6dB so that external gain setting is unnecessary. Both the BH3541F and BH3544F have
internal mute functions so that prevention of the popping sound when power is turned on and off is greatly simplified.
Also, these ICs are equipped with thermal shutdown circuits to prevent damage from short circuits.
Product name
BH3541F
BH3544F
Fixed gain
0dB
6dB
!
Applications
Devices that use the headphone output from CD-ROMs, CDs, MDs, personal computers, notebook computers,
camcorders, etc.
!
Features
1) Internal mute function to prevent popping sounds when the power is turned on and off.
2) Built-in thermal shutdown circuit (150擄C) to prevent damage to the IC if a short circuit occurs.
3) Compact SOP8 pin package.
!
Absolute maximum ratings
(Ta = 25擄C)
Parameter
Applied voltage
Power dissipation
Operating temperature
Storage temperature
Symbol
V
Max
Pd
Topr
Tstg
Limits
7.0
450
鈭?/div>
鈭?5
~
+75
鈭?5
~
+125
Unit
V
mW
擄C
擄C
鈭桼educed
by 4.5mW for each increase in Ta of 1擄C over 25擄C.
!
Recommended operating conditions
(Ta = 25擄C)
Parameter
Power supply voltage
Symbol
V
CC
Min.
2.8
Typ.
鈭?/div>
Max.
6.5
Unit
V
