BCX19CSM4
GENERAL PURPOSE NPN TRANSISTOR
IN A HERMETICALLY SEALED
CERAMIC SURFACE MOUNT PACKAGE
FOR HIGH RELIABILITY APPLICATIONS
MECHANICAL DATA
Dimensions in mm (inches)
V
CEO
= 45V
1.40 鹵 0.15
(0.055 鹵 0.006)
0.25 鹵 0.03
(0.01 鹵 0.001)
5.59 鹵 0.13
(0.22 鹵 0.005)
I
C
= 500mA
0.64 鹵 0.08
(0.025 鹵 0.003)
0.23 rad.
(0.009)
3
2
1.27 鹵 0.05
(0.05 鹵 0.002)
3.81 鹵 0.13
(0.15 鹵 0.005)
FEATURES
0.23 min.
(0.009)
4
1
鈥?SILICON PLANAR EPITAXIAL NPN
1.02 鹵 0.20
(0.04 鹵 0.008)
2.03 鹵 0.20
(0.08 鹵 0.008)
TRANSISTOR
鈥?HERMETIC CERAMIC SURFACE MOUNT
SOT 23 CERAMIC
(LCC3 PACKAGE)
PAD 1 = Collector
PAD 2 = No Collection
PAD 3 = Emitter
PAD 4 = Base
PACKAGE
鈥?CECC SCREENING OPTIONS
鈥?SPACE QUALITY LEVELS OPTIONS
ABSOLUTE MAXIMUM RATINGS
(T
case
= 25擄C unless otherwise stated)
V
CBO
V
CEO
V
EBO
I
C
P
D
P
D
R
ja
T
stg,
T
j
Collector - Base Voltage
Collector - Emitter Voltage
Emitter - Base Voltage
Collector Current
Total Device Dissipation
Derate above 50擄C
Thermal Resistance Junction to Ambient
Storage Temperature, Operating Temp Range
50V
45V
5V
500mA
350mW
2.0mW / 擄C
350擄C / W
鈥?5 to 200擄C
