BCW32LT1

General Purpose

Transistors

NPN Silicon

http://onsemi.com

MAXIMUM RATINGS

Rating

Collector-Emitter Voltage

Collector-Base Voltage

Emitter-Base Voltage

Collector Current 鈥?Continuous

Symbol

VCEO

VCBO

VEBO

IC

Value

32

32

5.0

100

Unit

Vdc

Vdc

Vdc

mAdc

1

BASE

COLLECTOR

3

2

EMITTER

THERMAL CHARACTERISTICS

Characteristic

Total Device Dissipation

FR-5 Board(1)

TA = 25擄C

Derate above 25擄C

Thermal Resistance,

Junction to Ambient

Total Device Dissipation

Alumina Substrate,(2) TA = 25擄C

Derate above 25擄C

Thermal Resistance,

Junction to Ambient

Junction and Storage Temperature

(1) FR鈥?5 = 1.0

0.75

(2) Alumina = 0.4

0.3

Symbol

PD

225

1

1.8

R

胃JA

PD

556

300

2.4

R

胃JA

TJ, Tstg

417

鈥?5 to

+150

mW/擄C

擄C/W

mW

mW/擄C

擄C/W

擄C

D2x

SOT鈥?3 (TO鈥?36AB)

CASE 318

STYLE 6

2

Value

Unit

mW

3

DEVICE MARKING





0.062 in.



0.024 in. 99.5% alumina.

x = Monthly Date Code

ORDERING INFORMATION

Device

BCW32LT1

Package

SOT鈥?3

Shipping

3000 Units / Reel

漏

Semiconductor Components Industries, LLC, 1999

1

January, 2000 鈥?Rev. 0

Publication Order Number:

BCW32LT1/D
