BCM5695 Datasheet

  • BCM5695

  • MULTILAYER 12 PORT GIGABIT ETHERNET STACKABLE SWITCH

  • 2頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

BCM5695
廬
MULTILAYER 12-PORT GIGABIT ETHERNET STACKABLE SWITCH
FEATURES
SUMMARY OF BENEFITS
鈥?/div>
12 10/100/1000-Mbps Ethernet ports with copper or fibre
connectivity
鈥?/div>
HiGig+鈩?stacking port that runs at 10-Gbps or 12-Gbps speeds
鈥?/div>
Integrated high-performance SerDes with XAUI鈩?interface on
the HiGig+ port and an SGMII interface on the
Gigabit Ethernet
(GbE) ports
鈥?/div>
Scalable up to 128 BCM5695 devices in a single configuration
鈥?/div>
Enables modular, scalable, and high-performance GbE switch
designs using switch fabric
鈥?/div>
Facilitates seamless integration of voice, video, and data traffic
through low-latency and advanced QoS
鈥?/div>
Enables lower system design cost and board space utilization
through superior integration and compact form factor
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
All address tables and buffer memory fully integrated on-chip
Support for port trunking and mirroring across stacked links
Support for jumbo frames of up to 9 KB in size
鈥?/div>
Offers quicker time-to-market and software reuse through
backward compatibility with Broadcom switch software API
Advanced full-duplex end-to-end flow and congestion control with
head-of-line blocking prevention
鈥?/div>
ContentAware鈩?packet filtering and classification per-port
鈥?/div>
Wirespeed operation
鈥?/div>
Support for 802.1p, TOS/DiffServ, policing, shaping, marking, and
remarking
鈥?/div>
Rate control of broadcast, unknown multicast and unicast packets
鈥?/div>
Eight queues per port
鈥?/div>
Support for double 802.1q VLAN tagging and VLAN translation
TARGET APPLICATIONS
鈥?/div>
Modular chassis-based Gigabit and 10-GbE switch solutions
for the core of enterprise networks
鈥?/div>
Scalable, stackable GbE switch solutions for distribution and
wiring closet of enterprise networks
鈥?/div>
High-performance standalone GbE switch solutions for
enterprise wiring closets and remote branches
鈥?/div>
Hardware-based IP multicast routing and forwarding
鈥?/div>
Support for replication
鈥?/div>
Equal and weighted cost multipath routing for load balancing
鈥?/div>
Advanced diagnostic features including JTAG boundary scan and
BIST functionality
鈥?/div>
Low power consumption of 4.65W in a 480-pin PBGA package
鈥?/div>
Embedded GbE switch solutions for blade server applications
within space-constrained data centers
鈥?/div>
Highly reliable GbE switch solutions for telecom applications
in central offices
鈥?/div>
Pin-to-pin compatible with the BCM5690
12-port Multilayer Gigabit Ethernet Switch with HiGig+
TM
Stacking
HiGig XAUI
(10/12 Gbps)
Layer 3
On-Chip Tables
HiGig
鈩?/div>
ARL
L3
Packet Buffer MMU
PCI
Internal Memory for
Nonblocking Performance
ContentAware
鈩?/div>
FFP
1-Gbps SerDes with
SGMII Support
PCI 32/66 Interface
I2C Interface
10/100/1000 MAC
12 x GbE
