Fast filter processor (FFP)
鈥?Examines up to the 80th byte of a packet
鈥?Supports ToS and DiffServ field modification
鈥?Bandwith regulation and monitoring per network flow
鈥?Network data flow tracking granular to 1 Mbps
鈥?/div>
New service offerings for ISPs.
鈥?Pay for bandwidth consumption.
鈥?Voice over IP.
鈥?Police over-consumption of network resources.
鈥?Line rate switching on all ports.
鈥?/div>
Greater insight to network resource utilization
through the advanced FFP features.
鈥?/div>
More efficient deployment of existing network
resources through insight provided by
StrataSwitch II
TM
feature set.
TM
鈥?/div>
Line rate switching on all ports for:
鈥?Layer 2 switching.
鈥?All FFP actions 鈥?steering, forwarding, reclassifying.
鈥?/div>
Low power of device, 5W (<250 mW/ FE port),
enables low-cost power supplies.
鈥?/div>
High level of integration minimizes PCB layer count
and routing issues.
鈥?/div>
Flexible (128 or 64 bit) SDRAM interface supports low
system cost of memory.
BCM5616 Application Diagram
2Mx32
SDRAM
2Mx32
SDRAM
2Mx32
SDRAM
2Mx32
SDRAM
PCI
Bus
StrataSwitch II
TM
BCM5616
8
8
8
BCM5238
BCM5238
BCM5238
BCM5402
