BCM5304M Datasheet

  • BCM5304M

  • 2頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

BCM5304M
PRODUCT
Brief
O F
B E N E F I T S
BCM5304M 5-PORT MANAGED 10/100BASE-T/TX SWITCH
B C M 5 3 0 4 M
F E AT U R E S
S U M M A R Y
鈥?/div>
5-Port 10/100 Switch Integrating the MACs, Switching
Fabric and 4 Transceivers into a Single Chip
鈥?/div>
Supports Full-Wire Speed, Full-Duplex Traffic on
Every Port Simultaneously
鈥?/div>
Cascadable up to 12 Ports, with a BCM5308M
鈥?/div>
Serial Management Port (SMP) Provided for CPU
鈥?/div>
Hardware support for SNMP, RMON, and Spanning Tree
鈥?/div>
On Board 32/64-Bit Counters Support Popular MIBs
256k
鈥?/div>
Glueless Interface to Low-Cost SingleBytesxor 512k Bytes
SSRAM, Configurable to use a
64k 32 Device
鈥?/div>
5.2 Gb/s Memory Bandwidth Provided per Device
鈥?/div>
MII Connection for External Phy (FX or TX)
鈥?/div>
2.6 Gb/s Expansion Port Cascades up to 3 Devices in a
Daisy-Chain Configuration
鈥?/div>
Flow Control: Full-Duplex (802.3x) and Half-Duplex
Options Supported
鈥?/div>
Direct LED Interface Provides Status on each Port
鈥?/div>
Low-Power 3.3V Design in .35碌 CMOS Technology
鈥?/div>
352-Pin TBGA Package
Optional 2nd
TX/FX Uplink Module
5201
鈥?/div>
World鈥檚 most integrated 10/100 managed switch
鈥?/div>
Lowest cost solution for SOHO and entry-level
corporate applications
鈥?/div>
Smallest form factor (reduces board space by 50%)
鈥?/div>
Scalable architecture supports 4 to 12 port densities
鈥?/div>
Fifth port supports any external Ethernet MII
transceiver
鈥?/div>
Eliminates cost of external LED latches and drivers
鈥?/div>
Robust and field-proven Digi-桅鈩?based 10/100
transceivers
鈥?/div>
Substantially simplifies board and system design
鈥?/div>
Integrated transceivers eliminate pin-intensive media
Independent Interface (MII)
鈥?/div>
Internal PLL generates all system clocks from a single
25 MHz source
Fully manageable with external CPU
Basic management statistics can be gathered and
reported with only a very low-cost microcontroller
鈥?/div>
鈥?/div>
12-Port Managed Switch Using SMP & 100 Mb/s Uplink Interface
TX/FX Uplink Port
D
5201
ODL
Mag
CPU
MII
SSRAM
MII
5304M
SSRAM
5308M
Quad
Magn.
Quad
Magn.
Quad
Magn.
LED Matrix
4 x RJ-45
LED Matrix
8 x RJ-45
12 Front Panel Ports
