BCM4413 Datasheet

  • BCM4413

  • 2頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

BCM4413
PRODUCT
BCM4413
B C M 4 4 1 3
Brief
CONTROLLER
O F
B E N E F I T S
PCI/MSI
F E AT U R E S
i L i n e 2 0
TM
S U M M A R Y
鈥?/div>
Combination HomePNA 2.0, 10/100 Ethernet, and V.90
PCI/Mini PCI modem with Fully Concurrent
Operation
Fully integrated iLine20 MAC/PHY, 10/100 Ethernet
鈥?/div>
MAC/PHY, and V.90 modem device for use in:
鈥?PCI/Mini PCI adapters
鈥?LAN on Motherboard
鈥?Internet Appliances and Broadband Gateways
鈥?Voice over IP (VoIP) Gateways
鈥?/div>
PC99 WHQL certified drivers for Windows 98,
Windows Millennium Edition, and Windows 2000
鈥?/div>
Meets PCI Power Management Interface v1.1 (ACPI)
鈥?/div>
HomePNA 2.0
鈥?iLine20 speed-doubling mode - twice the data rate of baseline
iLine10 HomePNA 2.0 solution
鈥?iLine20 is fully compatible with iLine10 and HPNA 1.0
鈥?Rate adaptive line rate from 4 Mbps to 32 Mbps
鈥?Low-latency real-time multimedia (DFPQ)
Each interface operates concurrently as a separate
鈥?/div>
function, providing independent communication
channels.
Represents the highest level of integration for
鈥?/div>
consumer Internet communications functions.
鈥?/div>
Provides the lowest cost per communications function.
Includes the
鈥?/div>
2.0 standard speed-doubling feature of the HomePNA
to support a maximum line rate of
32Mbps.
PCI
鈥?/div>
allowand Microprocessor Slave Interface bus options
integration into virtually any system.
for Windows 98, Windows
鈥?/div>
WHQL certified drivers for all three functions.
ME, and Windows 2000
鈥?/div>
All drivers are portable for embedded operating
systems.
鈥?/div>
10/100 Ethernet
鈥?Complete 10/100 MAC/PHY and driver solution
鈥?IEEE802.3u compliant Transmit and Receive engines
鈥?Integrated MIB counters
鈥?Low power 10BASE-T/100BASE-TX IEEE 802.3u Fast
Ethernet Transceiver
鈥?/div>
V.90 PCI Modem
鈥?High-performance V.90 software modem available
鈥?On-chip serial interface to external DAA/Codec
鈥?Efficient 鈥?uses only 30 MHz x86 CPU capacity
鈥?/div>
2.5/3.3 V supply, 3/5 V PCI I/O
鈥?/div>
196-ball FBGA
BCM4413 System Diagram
PCI BUS
or
MSI BUS
25 MHz
RJ-45
10/100 Ethernet
64 MHz
FILTER
TRANSFORMER
Phoneline
BCM4413
iLine20
BCM4100
FILTER
TRANSFORMER
RJ-11
V.90
CODEC
DAA
SERIAL
EEPROM
OPTIONAL
BOOT
ROM
STATUS
LEDs
