鈥?/div>
98SE
Meets PCI Power Management Interface v1.1 (ACPI)
IEEE 802.11b compliance
鈥?IEEE802.11b compliant MAC and Baseband
鈥?Interfaces to BCM2051 802.11b Single Chip Direct Conversion
Radio
鈥?WECA Wi-Fi November 2001 compliant
鈥?24-bit IV and 40-bit key WEP Encryption Support
鈥?24-bit IV and 104-bit key WEP Encryption Support
鈥?128-bit IV and 128-bit key WEP2 Encryption Support
鈥?SW and HW support for 128-bit OCB mode AES
鈥?IEEE 802.1x and LEAP support
鈥?Programmable 1, 2, 5.5, and 11 Mbps data rate
鈥?Dynamic power management under driver control
Each interface operates concurrently as a separate
鈥?/div>
function, providing independent communication
channels.
Represents the highest level of integration for portable
鈥?/div>
Internet communications functions.
鈥?/div>
Provides the lowest cost per communications function
Includes
Windows XP,
鈥?/div>
WindowsWHQL-certified drivers forWindows 98SE
ME, Windows 2000 and
廬
廬
廬
for all three functions.
鈥?/div>
鈥?/div>
10/100 Ethernet
MAC and driver solution
Complete 10/100
鈥?IEEE802.3u compliant transmit and receive engines
鈥?Integrated MIB counters
鈥?/div>
All drivers are portable for embedded operating
systems.
Mini PCI support provides ideal solution to laptop
鈥?/div>
manufacturers eliminating the need to compromise to
support 802.11b, V.92, and Ethernet functions.
High level of integration with direct conversion radio
鈥?/div>
architecture minimizes external circuitry leading to
lowest cost, lowest power, smallest footprint
implementation.
Supports
鈥?/div>
to provideindustry-standardized encryption algorithms
secure communications.
鈥?/div>
V.92 PCI modem
V.92 software modem available
鈥?High-performance
鈥?On-chip serial interface to external DAA/Codec
鈥?Efficient 鈥?uses only 30 MHz x86 CPU capacity
鈥?/div>
鈥?/div>
3.3/1.8V supply, 3/5V PCI I/O
196-ball PBGA package
BCM4307 System Diagram
RJ-45
Crystal
Magnetics
PHY
Balun
BCM2051
802.11b
Radio
Diversity
Switch and
BPF
T/R
Switch
Power
Amp
RJ-11
BCM4307
802.11b
MAC & BB,
V.92, 10/100
Bus
Interface
Balun
DAA
CODEC
BROADCOM PROPRIETARY & CONFIDENTIAL
