The Broadcom
BCM3036 is a complete
蟺/4
DQPSK,
QPSK and 16-QAM upstream burst Frequency Agile
Modulator, with a FEC encoder and a 10 bit D/A
Converter combined on a single chip for interactive
set-top boxes, or cable data modems with RF returns.
廬
鈥?/div>
A high-performance, integrated solution for
upstream modulation in cable data modems and
interactive cable-TV set-top boxes
鈥?/div>
Integrated Upstream Modulator
鈥?/div>
Significantly increases upstream channel bandwidth
鈥?/div>
Supports multiple standards for worldwide
deployment
鈥?Up to 8 Mbps data rates
鈥?Frequency agile output up to 42 MHz
鈥?/div>
Integrated D/A converter reduces system
manufacturing costs and complexities
鈥?/div>
Programmable Reed-Solomon Encoder
鈥?/div>
ITU-T J.83/Annex A (DVB/DAVIC/IEEE 802.14) and
Annex B (Digicipher II/SCTE/MCNS/IEEE 802.14)
compliant device
2
鈥?/div>
I C or SPI Compatible Microcontroller Interface
鈥?/div>
JTAG Test Interface
鈥?/div>
64-pin PQFP
Cable Modem or Interactive Set-Top Box Block Diagram
PA
LPF
BCM3036
Upstream
QPSK/16-QAM
Modulator
Gain Control
5-42 MHz
CLOCK
DATA
RAM
Coax
Connector
Diplex
Filter
BCM3220
MAC
MIcrocontroller
w/Enet MAC
ROM
CLOCK
DATA
54-860 MHz
44 MHz IF
Tuner
SAW
BCM3116/3118
QAM Receiver
w/FEC
10Base-T
Transceiver
RJ45
Connector
