BCM1101 Datasheet

  • BCM1101

  • THE MOST HIGHLY INTEGRATED SILICON SOLUTION FOR FEATURE ENGA...

  • 2頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

BCM1101
廬
ENTERPRISE IP PHONE CHIP
FEATURES
SUMMARY OF BENEFITS
鈥?/div>
The BCM1101 is the most highly integrated silicon solution for
feature enhanced Voice over IP enterprise phones
鈥?/div>
The BCM1101 Integrates:
鈥?/div>
150 MHz MIPS32 CPU (165 DMIPS) with 8K I-cache and 4K
D-cache
鈥?/div>
Superscalar 108 MHz ZSP DSP with dual-MAC (216 MIPS),
48K instruction and 32K data RAM
鈥?/div>
Three-port 10/100BASE-T Ethernet switch with 64K buffer
memory
鈥?/div>
Two 10/100BASE-T Ethernet PHYs with in-line power over
Ethernet support
鈥?/div>
Three wideband audio ADCs and DACs
鈥?/div>
9x9 keyscan controller
鈥?/div>
Ethernet status LED driver
鈥?/div>
TDM IOM-2
廬
port
鈥?/div>
Two UARTs
鈥?/div>
Two high-speed serial ports
鈥?/div>
General purpose I/O
鈥?/div>
Interrupt control unit
鈥?/div>
DMA support unit
鈥?/div>
SDRAM interface
鈥?/div>
External bus interface
鈥?/div>
IEEE 1149.1 (JTAG)
鈥?/div>
0.18碌 process technology, 1.8/3.3V
鈥?/div>
10/100BASE-T Ethernet Switch with 802.1p/Q Support
鈥?/div>
802.1p priority queuing ensures QoS for voice packets and
minimizes latency
鈥?/div>
Supports modification of 802.1p priority tags on packets to
enforce priority tagging rules
鈥?/div>
802.1Q VLAN support allows for segmenting physical
networks into multiple logical networks
鈥?/div>
MIPS32 CPU not burdened by data packet processing, leaving
more cycles for application program
鈥?/div>
Enables wire-speed non-blocking operation
鈥?/div>
Blocks unnecessary traffic by learning local MAC addresses
鈥?/div>
Segments network, preventing any restriction on number of
hops
鈥?/div>
150 MHz MIPS32 CPU and 108 MHz DSP Support
鈥?/div>
VxWorks/WinCE Operating Systems
鈥?/div>
SIP, H.323, H.248/Megaco, and MGCP
鈥?/div>
G.711, G.726, G.729A/AB/E, G.723.1/A, G.722.1 and
BroadVoice
廬
鈥?/div>
Full-duplex speakerphone operation
鈥?/div>
Handset echo suppression
鈥?/div>
Two- and three-channel conferencing using complex vocoders
鈥?/div>
Enhanced Packet Loss Concealment
鈥?/div>
Paging (via a G.711 channel)
鈥?/div>
Advanced user applications
鈥?/div>
10/100BASE-T Ethernet MACs and PHYs
鈥?/div>
Integrates support for Cisco in-line power specification
鈥?/div>
Compliant with 802.3af power over Ethernet standard
鈥?/div>
Provides auto-MDI/MDIX, enabling the use of straight or
crossover cables in either port
鈥?/div>
Wideband audio CODECs
鈥?/div>
Enables support of emerging wideband vocoding standards
鈥?/div>
1.1W peak, 0.3鈥?.8W standby modes
鈥?/div>
256-pin PBGA package enables 4-layer PCB designs
HARDWARE PLATFORMS
鈥?/div>
BCM91101 reference platform
鈥?/div>
Ethernet IP phone reference platform for mid-range IP Phones
designs
鈥?/div>
BCM91101SP reference platform
鈥?/div>
Ethernet IP Phone reference platform for feature enhanced,
touch screen IP Phone designs
