NPN SILICON PLANAR EPITAXIAL TRANSISTOR
BC368
TO-92
BCE
Transistor in TO-92 Plastic Package Intended for Low Voltage, High Current LF
Applications, Suitable for Class-B Audio Output Stages up to 3W
ABSOLUTE MAXIMUM RATINGS
DESCRIPTION
SYMBOL
VALUE
VCES
25
Collector -Emitter Voltage
VCEO
20
Collector -Emitter Voltage
VEBO
5.0
Emitter- Base Voltage
IC
1.0
Collector- Current
ICM
2.0
Collector- Current Peak Value
IB
100
Base- Current
IBM
200
Base- Current Peak Value
PTA
0.8
Power Dissipation @ Ta=25 deg C
PTC
1.0
@ Tc=25 deg C
Tj
150
Junction Temperature
Tstg
-65 to +150
Storage Temperature Range
Thermal Resistance
Rth (j-a)
156
Junction to Ambient in Free Air
Rth (j-a)
125
Junction to Ambient *
Rth (j-c)
60
Junction to Case
*Mounted on printed-circuit board , maximum lead length 4mm, mounting
pad for collector lead min 10 mm x10 mm
ELECTRICAL CHARACTERISTICS (Ta=25 deg C Unless Otherwise Specified)
DESCRIPTION
SYMBOL TEST CONDITION
ICBO
IE=0, VCB=25V
Collector Cut- off Current
Tj=150 deg C
IE=0, VCB=25V
VEB=5V, IC=0
IC=5mA, VCE=10V
IC=1A, VCE=1V
IC=1A, IB=100mA
UNIT
V
V
V
A
A
mA
mA
W
W
deg C
deg C
deg C/W
deg C/W
deg C/W
MIN
-
TYP
-
-
-
-
MAX
10
UNIT
uA
Emitter Cut- off Current
Base- Emitter on Voltage
Collector- Emitter Saturation Voltage
IEBO
VBE(on)
VCE(Sat)
-
-
-
-
-
-
1.0
10
0.7
1.0
0.5
mA
uA
V
V
V
