JIANGSU CHANGJIANG ELECTRONICS TECHNOLOGY CO., LTD
SOD-323 Plastic-Encapsulate
Diode
BAV19WS-BAV21WS
Features
1.00
SWITCHING DIODE
SOD-323
路
路
路
Fast Switching Speed
Surface Mount Package Ideally Suited for
Automatic Insertion
For General Purpose Switching Applications
1.70
Marking:
BAV19WS:A8
BAV20WS:T2
BAV21WS:T3
Unit:mm
1.30
2.65
Maximum Ratings
@ T
A
= 25擄C unless otherwise specified
Characteristic
Repetitive Peak Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Forward Continuous Current (Note 1)
Average Rectified Output Current (Note 1)
Non-Repetitive Peak Forward Surge Current @ t = 1.0ms
@ t = 1.0s
Repetitive Peak Forward Surge Current
Power Dissipation
Thermal Resistance Junction to Ambient Air (Note 1)
Operating and Storage Temperature Range
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
FM
I
O
I
FSM
I
FRM
P
d
R
qJA
T
j
, T
STG
BAV19WS
120
100
71
BAV20WS
200
150
106
400
200
2.5
0.5
625
200
625
-65 to +150
BAV21WS
250
200
141
Unit
V
V
V
mA
mA
A
mA
mW
K/W
擄C
Electrical Characteristics
Characteristic
Forward Voltage
Peak Reverse Current
@ Rated DC Blocking Voltage
Junction Capacitance
Reverse Recovery Time
@ T
A
= 25擄C unless otherwise specified
Symbol
V
FM
I
RM
C
j
t
rr
Min
戮
戮
Max
1.0
1.25
100
15
5.0
50
Unit
V
nA
mA
pF
ns
Test Condition
I
F
= 100mA
I
F
= 200mA
T
j
= 25擄C
T
j
= 100擄C
V
R
= 0, f = 1.0MHz
I
F
= I
R
= 30mA,
I
rr
= 0.1 x I
R
, R
L
= 100W
戮
戮
Note:
1. Valid provided that terminals are kept at ambient temperature.
0.30
1 /2
1
2
3
